YTO Brand 2.5 Tons CPD25 Battery Forklift Truck

US$ 10,000 - 20,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Henan, China

Brand Name:

YTO

Luoyang Mingyang Engineering Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Tianjing/Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Henan, China

Brand Name YTO

Model Number CPD25

Type Powered Pallet Truck

Power Souce Other, Storage Battery

Rated Loading Capacity 2500 Kg

Max. Lifting Height 4030 mm

Min. Lifting Height 2150 mm

Fork Length 1070 mm

Fork Width 125 mm

Overall Dimensions 2430*1150*2150

Certification CE & ISO9001 certification

After-sales Service Provided Engineers available to service machinery overseas

YTO Brand 2.5 Tons CPD25 Battery Forklift Truck

Technical Specifications:

Speciality parameter	Model					Unit	CPD25
	Power type						Battery
	Rated capacity					kg	2500
	Load center				d	mm	500
	Lift height				h2	mm	3000
	Mast tilt angle (forward/backward)				α/β	Deg	6/12
	Wheel-base				L4	mm	1500
	Tread(front/rear)				b4/b5	mm	970/950
Performance parameter	Travel brake						Hydraulic-Foot pedal
	Parking brake						Mechanical-Hand level
	Lift speed(with load)					mm/s	260
	Lower speed (with/without load)					mm/s	with load<600 ,without load>300
	Travel speed (without load)					km/h	12
	Max. gradeability (with load)					%	10
	Max. Towing (with/without load)					kN	9.8/8
	Weight Distribution with load(front/rear)						5900/840
	Weight Distribution without load(front/rear)						1825/2415
Power, transmission and others	Motor	Driving Motor	Model				XQ-6.3-1T
			Rated power			kw	6.3
			Rated rotation			r/min	1200
		Woring Motor	Model				XQD-8.6-C
			Rated power			kw	8.6
			Rated rotation			r/min	1550
	Controller	Manufacturer					CURTIS
	Controller	Type					MOSFET
	Battery	Voltage				V	48
	Battery	Capacity				Ah	360
		Size(L×W×H)					820×1065×520
	Gearbox	Transmission type					Mechanical
	Tire	type					Pneumatic tyre
		Model		Front			7.00-12-12PR
		Model		Rear			18×7-8-14PR
Others	Dead weight					kg	4240
	Free lift height				h4	mm	140
	Fork	Thickness×Width×Length			c×b×a	mm	40×125×1070
	Overall dimensions	Overall length(without forks)			L2	mm	2430
		Overall width			b1	mm	1150
		Overall height		Extended height(mast)	h1	mm	4030
				Lower height(mast)	h3	mm	1995
				Overhead guard	h7	mm	2150
	Min. turning radius				Wa	mm	2100
	Min. under ground clearance	Under mast			m1	mm	110
	Min. under ground clearance	Center of wheel-base			m2	mm	120
