Small Bulldozer SHANTUI Bulldozer SD13 and Spare Parts

Name: Small Bulldozer SHANTUI Bulldozer SD13 and Spare Parts
Brand: SHANTUI
SKU: 140736468
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

SHANTUI

Model Number:

SD13

Shanghai Dobest Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name SHANTUI

Model Number SD13

Condition New

Moving Type Crawler Bulldozer

Machine Weight 15.2t

Dimension(Long * Breadth * High) 4492*3185*2950mm

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Small Bulldozer SHANTUI Bulldozer SD13 and spare parts

SHANTUI SD13, SHANTUI SD16, SHANTUI SD22, SHANTUI SD23, SHANTUI SD32

Best Quality Chinese Bulldozer 130HP SHANTUI Bulldozer SD13 for Sale

Chinese Bulldozers SHANTUI construction machine sd13

Rated Power: 95.5kW/1900rpm
Engine Shangchai SC8D143G2B1 (D6114ZG4B)
Operating Weight: 15.2t

Dozer Type: Straight/Angle

Type	SSHANGCHAI D6114ZG4B (water cooled, in-line, direct injection and turbo charge)
Rated revolution	1900rpm
Rated power	95.5kw
Cylinder number-bore x stroke	6-114 x 135
Piston displacement	8.27L
Rated fuel consumption	<=228g/kW.h
Max. Torque	674.m/1300rpm

Under Carriage System

Type	Swing type of sprayed beam, suspended structure of equalizer bar
Carry rollers	2 each side
Track rollers	6 each side
Track type	Single teeth. Dry type
Width of track shoes	460mm
Pitch	190mm

Hydraulic System

Power Transmitting System

Torque converter	3-element, 1 stage, 1 phase
Transmission	Forced connected, planetary gear
Main drive	Spiral bevel gear, splash lubrication
Steering clutch	Wet, Multi-disc, spring loaded, hydraulic helping operation, mechanical separating, linking steering brake
Steering brake	Wet, floating, band type foot stepping brake with hydraulic helping
Final drive	2-stage speed reduction of spur gear, splash lubrication

Blade
