Chinese Bulldozers SHANTUI SD13, SHANTUI SD16, SHANTUI SD22, SHANTUI SD23, SHANTUI SD32
Best Quality Chinese Bulldozer 130HP SHANTUI Bulldozer SD13 for Sale
130 HP Series bulldozers SD13
Rated Power: 95.5kW/1900rpm
Engine Shangchai SC8D143G2B1 (D6114ZG4B)
Operating Weight: 15.2t
Dozer Type: Straight/Angle
Type |
SSHANGCHAI D6114ZG4B (water cooled, in-line, direct injection and turbo charge) |
Rated revolution |
1900rpm |
Rated power |
95.5kw |
Cylinder number-bore x stroke |
6-114 x 135 |
Piston displacement |
8.27L |
Rated fuel consumption |
<=228g/kW.h |
Max. Torque |
674.m/1300rpm |
Under Carriage System
Type |
Swing type of sprayed beam, suspended structure of equalizer bar |
Carry rollers |
2 each side |
Track rollers |
6 each side |
Track type |
Single teeth. Dry type |
Width of track shoes |
460mm |
Pitch |
190mm |
Hydraulic System
Max. Pressure |
14MPa |
Pump type |
Gear pump |
Discharge |
180L/min lated revelation |
Working cylinder x number |
90mm x2 |
Power Transmitting System
Torque converter |
3-element, 1 stage, 1 phase |
Transmission |
Forced connected, planetary gear |
Main drive |
Spiral bevel gear, splash lubrication |
Steering clutch |
Wet, Multi-disc, spring loaded, hydraulic helping operation, mechanical separating, linking steering brake |
Steering brake |
Wet, floating, band type foot stepping brake with hydraulic helping |
Final drive |
2-stage speed reduction of spur gear, splash lubrication |
Blade
Blade |
Straight-tilt |
Angle |
Min. Ground clearance(mm) |
320 |
320 |
Operating weight(kg) |
14000 |
14500 |
Ground pressure(MPa) |
0.064 |
0.064 |
Gradeability |
30 |
30 |
Track gauge(mm) |
1880 |
1880 |
Dozing capacity(m3) |
3.7 |
3.4 |
Blade height(mm) |
1090 |
915 |
Blade width(mm) |
3185 |
3745 |
Max. Drop below ground(mm) |
590 |
590 |
Max. Tilt adjustment(mm) |
400 |
400 |
Travel Speed
Gear |
1st |
2nd |
3rd |
Foward(km/h) |
3.2 |
5.9 |
9.8 |
Reverse(km/h) |
3.9 |
7.1 |
11.9 |
The warranty covers the Product, for one (1) year from the documented date of purchase.
We promise excellent service under the warranty:
1. We will send the new spare parts by air express, such as DHL or TNT once our customers request an urgent replace of broken parts under warranty
2. We will arrange engineers to service machinery overseas in case our customers are in need help for installation and training, such as tower cranes, concrete batching plant, asphalt mixing plant, stone crushing plant, etc.
3. We will send original spare parts by shipment or air express for option in case our clients want to purchase some other spare parts for repair and regular maintenance of their machines.
As a leading exporter specially for a big variety of construction equipment, Shanghai Dobest Construction Machinery Co., Ltd. is located in China's biggest port city Shanghai, which is also the financial center and business center.
Our mission is to provide a 'one-stop' service to fulfill our customers’ needs and expectations with the high quality product, prompt delivery and perfect service after sales. We promise to do our best to make our customers satisfied as we offer professional construction solutions for their kinds of projects.
By keeping the principle of good quality, competitive price, superior service, now we have won a very good reputation from all of our customers all over the world. Thus, our business expanded rapidly and so far we have exported our products to more than 20 countries and regions, including Australia, New Zealand, Brazil, Argentina, Honduras, Algeria, Tanzania, Kenya, Ethiopia, Djibouti, Congo, Morocco, UAE, Saudi Arabia, Iraq, Singapore, Thailand, Malaysia, Philippines and etc. Our market is mainly in Africa, South America, Middle East, South East Asia and some European countries.
We devote ourselves to provide a wide range of Chinese well-known construction equipment series to fulfill our customer’s different demands for their projects.
