YTO CPQD30 Gasoline Forklift 3T LPG for Sale Including Tanks

Evangel Industrial (Shanghai) Co., Ltd.

US$ 2,000 - 3,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Brand Name:

YTO

Model Number:

CPQD3

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name YTO

Model Number CPQD3

Type Powered Pallet Truck

Power Souce Gasoline Engine

Rated Loading Capacity 3000kg

Max. Lifting Height 3000mm

Min. Lifting Height 160MM

Fork Length 1070mm

Fork Width 125MM

Overall Dimensions 2625*1225*2250mm

Certification ISO,CE,GOST

After-sales Service Provided Engineers available to service machinery overseas

YTO CPQD30 Gasoline Forklift 3T LPG for sale including tanks

Main features:

3ton Gasoline Forklift CPQD30
1.Rated load:3000kg
2.Max lifting height (standard mast):3m
3.Fork length (standard):1070mm

Technical Specification

Model			CPQD20	CPYD20	CPQD25	CPYD25	CPQD30	CPYD30
Power type			Gasoline	LPG	Gasoline	LPG	Gasoline	LPG
Rated capacity		kg	2000	2000	2500	2500	3000	3000
Load center	d	mm	500	500	500	500	500	500
Lift height	h2	mm	3000	3000	3000	3000	3000	3000
Mast tilt angle (forward/backward)	α/β	Deg	6/12	6/12	6/12	6/12	6/12	6/12
Front overhang	L3	mm	465	465	465	465	485	485
Wheel-base	L4	mm	1600	1600	1600	1600	1700	1700
Tread(front/rear)	b4/b5	mm	960/970	960/970	960/970	960/970	1000/980	1000/980
Travel brake			Hydraulic-Foot pedal
Parking brake			Mechanical-Hand level
Lift speed(with/without load)		mm/s	440/500	440/500	440/500	440/500	360/450	360/450
Lower speed (with/without load)		mm/s	(with load)<600 ,(without load)>300
Travel speed (with/without load)		km/h	18/19	18/19	18/19	18/19	18/19	18/19
Max. gradeability (with load)		%	20	20	20	20	20	20
Max. Towing (with/without load)		kN	16/13	15/12	17/14	16/13	19/15	18/14
Weight Distribution with load(pront/rear)		kg	4665/635	4700/650	5455/745	5500/750	6350/870	6395/875
Weight Distribution without load(pront/rear)		kg	1255/2045	1270/2080	1400/2300	1425/2325	1600/2620	1620/2650
