Help CenterFully Automatic Hydraulic Extrusion Blow Molding Machine JKB60-2LII
Related Products
-
Fully Automatic Hydraulic Extrusion Blow Molding Machine JKB50-2LUS$ 20,000 - 200,000MOQ: 1 Set -
Extrusion Blow Molding MachineUS$ 1,000 - 10,000MOQ: 1 Set
-
Fully Automatic Hydraulic Extrusion MachineUS$ 20,000 - 200,000MOQ: 1 Set
-
Extrusion Blow Moulding MachineUS$ 1,000 - 100,000MOQ: 1 Set
-
1000T Model JSE-1000 Plastic Table Injection Molding Machine 1#NegotiableMOQ: 1 Set
Specifications
raw material: PE, PP, PVC, PC, ABS, TPU,lower energy consumption
Microcomputer intellectualized controlling
Self-diagnosis
Extrusion Blow Molding Machine, extrusion machine
Description:
Extrusion blow molding machine is used to produce PVC, PE, PP bottles, jar, cans, barrels and other containers in regular shapes. Our extrusion blow molding machines include PC 5 gallon blow molding machine and hydraulic blow molding machine. These machines are characterized by high productivity, energy efficiency, good molding quality and pollution-free quality.
At Joysun, we aims to offer high quality extrusion blow molding machine at lowest costs. To this end, we purchase our raw materials in bulk and have established long-term partnership with our shippers and material suppliers. As a China manufacture, we enjoy low land, labor and material costs. As a result of commitment to cost control, our extrusion blow molding machines, plastic cap injection molding machine, PET blow molding machine and more plastic processing machines are popular in India, Australia, Spain, Mexico, South Africa, Malaysia, Brazil, Vietnam, Japan and other countries.
Configuration:
Siemens PLC, Italy pneumatic component, international famous electric component.
Characteristics:
1, Microcomputer intellectualized controlling, self-diagnosis alarm, clear at a glance,
2, Hydraulic system with imported proportional valve, lower energy consumption. At the same time, a significant reduction in oil temperature extends the service life of hydraulic parts.
3, Variety of functions for different products matching the technological requirements: bottom blow and lift, rotation, encapsulation, material support, sub-mould, robot, parson control system, de-flashing system, etc.
Parameter:
| ITEM | UNIT | JKBA82-25PC | JKBA80-30l | JKBA90-60L |
| Max. Product VOLUME | L | 25 | 30 | 60 |
| Dry Cycle | pcs/h | 600 | 650 | 500 |
| Screw Diameter | mm | 82 | 80 | 90 |
| Screw L/D Ratio | L/D | 38 | 25 | 25 |
| Screw Drive Power | KW | 30 | 37 | |
| Screw Heating Power | 4Φkw | 16.7 | 16 | 21 |
| Screw Heating Zone | Zone | 8 | 4 | 4 |
| HPDE Output | kg/h | 160 | 100 | 140 |
| Oil Pump Power | kw | 11 | 15 | 18.5 |
| Clamping Force | kn | 215 | 220 | 350 |
| Mold Stroke | mm | 240-620 | 400-830 | 500-1050 |
| Max.Mold Size | W*H(mm) | 600*700 | 600*700 | 700*1050 |
| Accumulator Capacity | L | 1.85 | 4 | 6.6 |
| Max.Die Diameter | mm | 150 | 300 | 350 |
| Die Heating Power | 4Φkw | 4.5 | 11.9 | 17 |
| No. of Heating Zone | Zone | 4 | 4 | 4 |
| Blowing Pressure | Mpa | 0.8 | 0.8 | 0.8 |
| Air Consumption | m³/min | 0.4 | 0.8 | 1 |
| Cooling Water Pressure | Mpa | 0.3 | 0.3 | 0.3 |
| Water Consumption | L/min | 30 | 60 | 85 |
| Machine Size | L*W*H(m) | 6.2*2.3*4.5 | 4.23*2.3*3.5 | 4.75*2.5*3.9 |
| Machine Weight | Ton | 11.8 | 11.5 | 12.8 |
| ITEM | UNIT | JKBA100-90L | JKBA100-120L | JKBA120-160L |
| Max. Product VOLUME | L | 90 | 120 | 160 |
| Dry Cycle | pcs/h | 360 | 360 | 300 |
| Screw Diameter | mm | 100 | 100 | 120 |
| Screw L/D Ratio | L/D | 25 | 28 | 28 |
| Screw Drive Power | KW | 45 | 55 | 75 |
| Screw Heating Power | 4Φkw | 24 | 24 | 30 |
| Screw Heating Zone | Zone | 4 | 4 | 5 |
| HPDE Output | kg/h | 180 | 200 | 250 |
| Oil Pump Power | kw | 22 | 37 | 45 |
| Clamping Force | kn | 500 | 650 | 800 |
| Mold Stroke | mm | 550-1250 | 550-1400 | 600-1500 |
| Max.Mold Size | W*H(mm) | 800*1000 | 800*1250 | 1100*1500 |
| Accumulator Capacity | L | 12 | 14 | 18 |
| Max.Die Diameter | mm | 430 | 450 | 520 |
| Die Heating Power | 4Φkw | 20 | 21 | 25 |
| No. of Heating Zone | Zone | 5 | 5 | 5 |
| Blowing Pressure | Mpa | 0.8 | 0.8 | 0.8 |
| Air Consumption | m³/min | 1.2 | 1.6 | 1.6 |
| Cooling Water Pressure | Mpa | 0.3 | 0.3 | 0.3 |
| Water Consumption | L/min | 100 | 150 | 180 |
| Machine Size | L*W*H(m) | 5.4*2.5*4 | 5.4*2.6*4.2 | 5.8*2.6*4.4 |
| Machine Weight | Ton | 16 | 19 | 22 |
Flow Chart
Machine Picture
Production
