Specifications
extrusion molding machinePneumatic,
Max volume: 1000L, for milk bottle, beverage bottle, medicine bottle, etc.
Extrusion Blow Molding Machine, extrusion machine
Application: All kinds of plastic bottle made of PC, such as 5 gallon bottle.
Max. Bottle Volume: 25L.
Configuration: Siemens PLC, Italy pneumatic component, international famous electric component.
Characteristics:
1. Microcomputer intellectualized controlling;
2. fully pneumatic clamping, tight structure;
3. Accurate and steady forming, high production capacity.
Item |
Unit |
JKBA82-25PC |
Max. Product Volume |
L |
25 |
Dry Cycle |
pcs/h |
600 |
Screw Diameter |
mm |
82 |
Screw L/D Ratio |
L/D |
38 |
Screw Drive Power |
kw |
|
Screw Heating Power |
3Φkw |
16.7 |
Screw Heating Zone |
Zone |
8 |
HPDE Output |
kg/h |
160(PC) |
Oil Pump Power |
kw |
11 |
Clamping Force |
KN |
215 |
Mold Stroke |
mm |
240-620 |
Max. Mold Size |
W×H(mm) |
600×700 |
Max. Die Diameter |
mm |
150 |
Die Heating Power |
4Φkw |
4.5 |
NO. of Heating Zone |
Zone |
4 |
Blowing Pressure |
Mpa |
0.8 |
Air Consumption |
M³/min |
0.4 |
Cooling Water Pressure |
Mpa |
0.3 |
Water Consumption |
L/min |
30 |
Machine Size |
L×W×H(mm) |
6.3×2.3×4.5 |
Machine Weight |
Ton |
11.8 |
