Specifications
extrusion blow moulding machinePneumatic,
Max volume: 1000L, for milk bottle, beverage bottle, medicine bottle, etc.
Extrusion Blow Molding Machine, extrusion machine
Application: All kinds of plastic bottle made of PE, PP, such as milk bottle, beverage bottle, medicine bottle, etc.
Max. Bottle Volume: 1000L.
Configuration: Siemens PLC, Italy pneumatic component, international famous electric component.
Characteristics:
1. Microcomputer intellectualized controlling;
2. fully pneumatic clamping, tight structure;
3. Accurate and steady forming, high production capacity.
Item |
Unit |
JKB90-12LII |
Max. Product Volume |
L |
12 |
Dry Cycle |
pcs/h |
600×2 |
Screw Diameter |
mm |
90 |
Screw L/D Ratio |
L/D |
25 |
Screw Drive Power |
kw |
37 |
Screw Heating Power |
3Φkw |
8.8 |
Screw Heating Zone |
Zone |
4 |
HPDE Output |
kg/h |
130 |
Oil Pump Power |
kw |
11 |
Clamping Force |
KN |
110 |
Mold Stroke |
mm |
240-620 |
Max. Mold Size |
W×H(mm) |
530×520 |
Max. Die Diameter |
mm |
230 |
Die Heating Power |
4Φkw |
3 |
NO. of Heating Zone |
Zone |
3 |
Blowing Pressure |
Mpa |
0.6 |
Air Consumption |
M³/min |
0.8 |
Cooling Water Pressure |
Mpa |
0.3 |
Water Consumption |
L/min |
60 |
Machine Size |
L×W×H(mm) |
4.1×2.8×3.1 |
Machine Weight |
Ton |
11 |
