Specifications
wire drawing machine price1.Direct factory
2.Max incoming dia.: 8mm
3.Min outgoing dia.: 1.1mm
4.ISO9001,BV certification
Wire Drawing Machine
HTK'S Wire Drawing Machine is one of our main products,it has the advantage of easy control,low in nosie,low cost with high effiency, we have two senior engineers, 10 senior technicians ,we have a good reputation of after-sale service in our customer.
The specification of Wire Drawing Machine
|
Item
|
Unit |
8/80 |
10/560 |
10/550 |
10/450 |
Capstan dia |
mm |
600 |
560 |
550 |
450 |
Material strength |
Mpa |
1150 |
1150 |
900 |
1300 |
Max incoming dia |
mm |
8-6 |
6.5 |
6.5 |
3.6 |
Min outgoing dia |
mm |
3-2 |
1.8 |
1.8 |
1.1 |
Total compressibility |
% |
85 |
92.33 |
92.33 |
90.7 |
Max line speed |
m/min |
300 |
400 |
400 |
400 |
Single motor power |
kw |
37-30 |
30-18.5 |
22-15 |
18.5-7.5 |
Weight |
kg |
3000 |
2500 |
2200 |
2000 |
Dimensions |
m |
2x1.2x2.6 |
1.7x1.1x2.4 |
1.52x0.82x2.3 |
1.52x0.82x2.2 |
Max average compressibility |
% |
25 |
25 |
25 |
21 |
Notes: 1. Guarantee period: one year
2. Engineer s can install, test and adjust the machine for you.
3. 24 hours online service
