Professional Supplier Wire Drawing Machine
- 2 Set / Sets per Month
- xingang tiangang China
- T/T
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- DOING supply photovoltaic solar panels recycling machine
- four-axis welding machine for commercial sink panel and bowl
- Double Platform Stainless Steel Kitchen Equipment Polishing Machine
- Photovoltaic solar panels recycling plant
- Solar panel recycling machine with high efficiency
Product Details
Brand Name: | HTK | Model Number: | HTK-LW | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Wire Drawing machine1.Direct factory
2.Max incoming dia.: 8mm
3.Min outgoing dia.: 1.1mm
4.ISO 9001 and BV certification
Wire Drawing Machine
HTK'S Wire Drawing Machine is one of our main products,it has the advantage of easy control,low in nosie,low cost with high effiency, we have two senior engineers, 10 senior technicians ,we have a good reputation of after-sale service in our customer.
The specification of Wire Drawing Machine
Item
| Unit | 8/80 | 10/560 | 10/550 | 10/450 |
Capstan dia | mm | 600 | 560 | 550 | 450 |
Material strength | Mpa | 1150 | 1150 | 900 | 1300 |
Max incoming dia | mm | 8-6 | 6.5 | 6.5 | 3.6 |
Min outgoing dia | mm | 3-2 | 1.8 | 1.8 | 1.1 |
Total compressibility | % | 85 | 92.33 | 92.33 | 90.7 |
Max line speed | m/min | 300 | 400 | 400 | 400 |
Single motor power | kw | 37-30 | 30-18.5 | 22-15 | 18.5-7.5 |
Weight | kg | 3000 | 2500 | 2200 | 2000 |
Dimensions | m | 2x1.2x2.6 | 1.7x1.1x2.4 | 1.52x0.82x2.3 | 1.52x0.82x2.2 |
Max average compressibility | % | 25 | 25 | 25 | 21 |
2. The characteristic of wire drawing machine
1. Powered motor
2. High speed
3. Smart programmable control and operation
4. High safety standard
5. Efficient and cost-effective
3.After sale service:
NO.1 Engineer can install,test and adjust,repair the machine for you
NO.2 Guarantee: One year, If the machine has something wrong, the accessories also can free to you
NO.3 24 hours online after-sale service
NO.4 We will train worekers for you
4.Our Factory:
Hebei HTK Welding Equipment Manufacture Co., Ltd
We have 2 senior engineers,10 senior technicians,more than 100 employees
1>. Our products: Field Fence and Field Fence Machine, Wire drawing machine
2>. Our certifications: ISO 9001:2000, BV certification
3>. Our Main Market:South Africa, Mongolia,Asia, Dubai
5.Advantage of HTK factory
A. We have professional engineer supervision
B. The price preferential benefit
C. Product quality assurance
D. High production efficiency
E. With credibility and protection
F. Can visit the factory in person
G. Good after sales service
H. Business model: Factory direct
