7.5KW Industrial Fan Electric Motor Y2-132
- QingDao
- T/T
You May Like
Product Details
| Brand Name | PengSheng | Model Number | Y2 | |
| Type | Asynchronous Motor | Frequency | 220V,380V,440V,415V,660V,etc | |
| Output Power | 5.5-355KW | Protect Feature | Explosion-proof | |
| Phase | Three-phase | Certification | Other, ISO9001 | |
| AC Voltage | 208-230 / 240 V | Place of Origin | Shandong, China | |
| Efficiency | IE 1 |
Product Description
7.5KW Industrial Fan Electric Motor Y2-132
1. Double painting of winding.
2. The screws on the front shield and the fan cover in stainless steel.
3. Thermal protection of winding as standard.
4. Control and power glands in the base price.
5. Reduced vibration by max. 1.5 mm/s.
6. Each motor goes through routine tests and the test result is delivered together with motor.
7. Engines above axial height 132 is provided with bearing shields made of cast iron.
Brand Name | ZODA |
Model Number | |
Type | Induction Motor |
Frequency | 50/60Hz |
Output Power | 5.5 to 355kW |
Frame size | 132-355mm |
Phase | Three-phase |
Certification | CE, IEC, ISO9001 |
AC Voltage | 220/380V,380/660V or on your request |
Efficiency | IE3, IE2, IE1 |
Frame | Cast Iron |
Poles | 2, 4, 6, 8, 10,12,14 |
Ambient temperature | -15° to +40°c |
Altitude | <1000 a.s.l |
Relative humidity | Not higher than 95% |
Duty | Continuous(S1) |
Connection | "Y" type for 3kW and downwards, "D" type for 4kW and upwards |
Insulation Class | Class F/H |
Protection Class | P55 |
Mounting types | IMB3/IMB35/IMV1 or on your request |
Cooling Method | IC 411 (total-enclosed fan-cooled type) |
Temperature | 3*PTC or 3*PT100 for Winding, 2*PTC or 2* PT100 for bearing |
Price | USD or EUR |
Minimum Order Quantity | 10 Piece/Pieces, USD |
Packaging Details | Wood box. |
Delivery Time | 30 days after receipt L/C or T/T |
Payment Terms | L/C,D/P,T/T,D/C |
Supply Ability | 30,000 Piece/Pieces per Month |
Special motors can be designed according to customers' requirements
Y2 series motor is totally enclosed, fan cooled, squirrel-cage three-phase asynchronous motor, three-phase asynchronous motor can adopt inverter power supply, and is a new generation of low voltage three-phase asynchronous motor optimized on the basis of Y series motor. Basic series products comply with IEC and DIN standards, with international generality, is the ideal product to export and replace the imported products. This series has applied for the enterprise standard, the standard number: Q/320292ANV15-2012.
Y2 series motor is characterized by high efficiency, energy saving, low vibration, reliable performance, convenient maintenance, beautiful and novel appearance, is a typical application of energy saving motor, which adopts advanced electromagnetic calculation and special insulation system, makes products the more suitable for the inverter power supply system, comparing with Y series, Y2PF improves protection level (IP54 or IP55), insulation level (F) according to the assessment of class B, reduces the noise, and with the load noise assessment, the motor structure more reasonable. Cooling method is IC411. Insulation dimension and power level are fully conform to the IEC standard and DIN42673 standard.
Y2PF series motors are widely used for driving all kinds of machinery and equipment, motor rated voltage 380V, rated frequency 50Hz, frequency range 30-60Hz, constant torque 30-50Hz, constant power 50-60Hz, products also can confirm voltage and frequency at rated point according to customer’s needs,. 3kW and below is Y connection, 4kW and above is delta connection, ambient temperature is not more than 40℃, altitude is less than 1000m.a.s.l, duty is continuous (S1).
1. Cast Iron Frame 2. Copper wire 3. Three Phase Motors 4. Customized Production is available.
5. Supply for OEM
6. 100% tested for the quality prior to shipment
7. Certificate and Guarantee: ISO 9001:2008&CE
8. Package: Wooden case
Packing &Shipping
Company Profile
Certification
Our Advantage
1.Small volume, high air volume, high efficiency, low noise, light vibration,easy to installation and so on.
2.Widely applied for the ventilation in dwellings, industrial constructions and labs, in environment with strict limit to noise, or in air conditioning, air purifying and freezing industries etc.
3.The fan adopts mold production through static and dynamic balance adjustment, and its surface adopts high-grade electrostatic spraying treatment.
4.The gas delivered by the series of fan cannot have sticky matters, and is noncorrosive, non-flammable and non-explosive.
FAQ
Why choose Qingdao Peng Sheng Electrical Appliance Co., Ltd.?
1.Good quality, Competitive price, Fast delivery.
2. We have a R&D team who have average 10 years experience in designing and producing fans, we can OEM different kinds of products according to your requirement,
in order to produce the products more suitable to your market !
3. We have a lot of customers from overseas. A lot of our customers has established long term business relationship with us.
4. All the products have 1 year warranty. All products are conducted strict QC and inspection before shipping.
5. If you have any problems or suggestions about our products or service, you can contact me or our sales manager whenever you want. We will give you a satisfying reply.
Contact Way

If you can't find the datas you need, pls send us your performance requirements,
we will provide you customized design service in 8 hours.
Skype :qdpsdq.dong
Mobile :+86 13964294505
My name : Zhengdong Lu
