Low Cost Wireless Battery-supplied Applications Transceiver RF Module

Name: Low Cost Wireless Battery-supplied Applications Transceiver RF Module
Brand: Friendcom
SKU: 140580150
Availability: InStock

Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Friendcom

Model Number:

FC-701

Shenzhen Friendcom Technology Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Friendcom

Model Number FC-701

Specification :

FC-RF701 is a super-low consumption RF transceiver designed for battery-supplied applications such as water, gas and heat meter AMR

·It works in ISM band 433MHz, 475MHz or 868MHz

·Adopts timing sleep and wake-up detecting to guarantee the super-low consumption

Applications

·AMR for water, gas and heat meter

·Intelligent home control system

·Wireless sensor

·Automatic data collection system

·Wireless remote control

Technical specifications

Power supply	+2.9 to +3.6V DC
Metering accuracy	100L
Work frequency	433/470MHz
RF power	17.5 to 19dBm
TX current	70mA (minimum), 80mA (typical value), 90mA (maximum)
RX sensitivity	-103dBm (minimum), -104dBm (typical value), -105dBm (maximum)
RF data rate	10Kbps
RX current	4.6mA (minimum), 4.8mA (typical value), 5.0mA (maximum)
Sleep current	4.5uA (minimum), 4.8uA (typical value), 5.1uA (maximum)
Breath cycle	1s
Wake-up time	4.8ms
Modulation	FSK
Channel number	10
Point-to-point distance	300m (minimum), 330m (typical value), 390m (maximum), in line of sight
Operating temperature	-40°C (minimum), 25°C (typical value), 85°C (maximum)
Humidity	10 to 90%% RH, no condense
Dimensions	51 × 27 × 5mm
