Size: 420*240*28mm
Product mode explanation
Model |
Interface |
CF-RU5114 |
Standard(RS232, RS485, Wiegand) |
CF-RU5114U |
USB |
CF-RU5114T |
Standard with tcp/ip |
CF-RU5114w |
Standard with Wifi |
General Description
CF-RU5114 is a high performance UHF RFID integrated reader. It is designed upon fully self-intellectual property. Based on proprietory efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, anti-counterfeit and industrial production process control system.
FEATURES
- Self-intellectual property;
- Support ISO18000-6B, ISO18000-6C(EPC C1G2) protocol tag;
- 865~868MHz, 902~928MHz frequency band(frequency customization optional);
- FHSS or Fix Frequency transmission;
- RF output power up to 30dbm(adjustable);
- 12dbi antenna optional with effect distance up to 0-2m*;
- Support auto-running, interactive and trigger-activating work mode;
- Low power dissipation with single +9 DC power supply;
- Support USB, RS232, RS485, Wiegand, TCP/IP interface;
* Effective distance depends on antenna, tag and environment.
CHARACTERISTICS
- Absolute Maximum Rating
ITEM |
SYMBOL |
VALUE |
UNIT |
Power Supply |
VCC |
16 |
V |
Operating Temp. |
TOPR |
-10~+55 |
℃ |
Storage Temp. |
TSTR |
-20~+75 |
℃ |
- Electrical and Mechanical Specification
Under TA=25℃,VCC=+9V unless specified
ITEM |
SYMBOL |
MIN |
TYP |
MAX |
UNIT |
Power Supply |
VCC |
8 |
9 |
12 |
V |
Current Dissipation |
IC |
|
350 |
650 |
mA |
Frequency |
FREQ |
902 |
|
928 |
MHz |
Interface
Item |
Comment |
Red |
+9V |
Black |
GND |
Yellow |
Wiegand DATA0 |
Blue |
Wiegand DATA1 |
Purple |
RS485 R+ |
Orange |
RS485 R- |
Brown |
GND |
White |
RS232 RXD |
Green |
RS232 TXD |
Grey |
Trigger input(TTL level) |
