13.56mhz rfid ic chip card reader writer with SDK,demo software,user manual and source code for software development
Product description:
CF-RH320 series desktop readers are smart modules without touching based on international standard agreement ISO14443A/B,ISO15693
CF-RH320 are equipped with high capability chip, processor, security and electric monitor. The reader can communicate with PC by means of interface.
CF-RH320 are of high capability, anti-jamming, small size and good quality, which brings more convenience.
Product mode explanation:
Model | standard | interface | color |
CF-RH321 | IS014443A | U(USB)/R(RS232) | B(black)/W(white) |
CF-RH322 | IS014443A/B | U(USB)/R(RS232) | B(black)/W(white) |
CF-RH323 | ISO15693 | U(USB)/R(RS232) | B(black)/W(white) |
CF-RH324 | ISO/IEC14443A/B,ISO15693 | U(USB)/R(RS232) | B(black)/W(white) |
Capability specifications:
Name | HF Reader&write |
Dimension | 104x68x10mm |
Standard | ISO 14443A |
Support | Mif One S70; Mif One UltraLight; Mif One S50 |
Frequency | 13.56MHz |
speed | 106kbit/s |
Baud Rate | 9600 bit/s |
Power Supply | +5V DC |
Consumed Current | < 80Ma |
Operating Distance | 50--70mm |
Interface | USB/RS232 |
Status Indication | 1pcs LED;1pcd buzzer |
Service Temperature | -10°C ~ +70°C |
Store Temperature | -20°C ~ +80°C |
Application;
Widely used in access control, attendance, conference attendance, medical insurance, hotels, highways, petrol stations, parking, public transportation, such as toll collection system.
Other support:
1.The reader come with the completed English SDK,demo software,user manual and source code,and these documents will help you develop the softwre.
2.When you buy our reader,we can provide free card to you for testing.
3.More exact product information,please come to below link to check:
/product.aspx?cid=237
Product picture
