5ports Gigabit POE Switch 4chs 10/100M POE Ethernet Ports One 1000M Uplink Port Switch 150M Range 48V 24V Optional

Brief Introduction:

Adopts single port full-power technology, and single port supports Max.30W and feeds enough power to Array IR CCTV cameras. Auto-detect and recognize IEEE 802.3AF/IEEE 802.3AT standard PD (Powered Devices) and feeds power to it. Supports smart power management, if the power of PD over 53W, the system will stop feeds low-priority devices. Has smart POE auto-recognized system to protect devices from overflow current and over -voltage etc. Adopts Auto-standby mode and cable distance detection management to ensure the switch has excellent energy saving capability. Using imported original industrial components and Gold-plated PCB. All RJ45 ports adopt advanced Self-healing multi-stage lightning protection design, have high-level lightning, surge and ESD protection. Support 1+1 dual power supply backup, can be used in harsh conditions for long time.

Product Feature:

4channels 10/100M Ethernet POE switch ,one 10/100M/1000M Uplink Ethernet port.

Adopts import industry PSE chip and Taiwan YDS transformer.

Supports IEEEE802.3X,IEE802.3u,IEE802.3z/ab,IEE802.1q, IEE802.3a protocol, Auto-detect and recognize IEEE 802.3AF/IEEE 802.3AT standard PD (Powered Devices) and feeds power to it.

Support VLAN Network isolation and BSTM broadcast storm-control setting.

Supports Auto-standby mode and cable distance detection management, if no devices been connected, then auto-standby to save energy, if cable distance less than 10meters,then will use Lower transmission power.

Smart POE auto-recognized system to protect devices from overflow current and over -voltage etc.

2K MAC address.

Support 1+1 dual power supply backup, Supports 24hours power feeds.

Supports line speed switching of all ports and in 64~1536 frame length can reach line speed.
