2014 standard automatic filling machine pure water filling machine
Form
model | NC12-12-5 | NC16-16-5 | NC18-18-6 | NC24-24-8 | NC32-32-8 | NC40-40-10 |
production capacity | 4000 | 6000 | 8000 | 10000-12000 | 13000-15000 | 16000-18000 |
gas source pressure(mpa) | 0.2 | 0.2 | 0.4 | 0.4 | 0.5 | 0.55 |
total power(kw) | 4.6 | 4.6 | 5.4 | 6.4 | 8.07 | 9.56 |
Total weight(kg) | 2500 | 3200 | 3800 | 5200 | 6500 | 8000 |
Dimension (L*W*H)mm | 2350*1700*2150 | 2600*1830*2030 | 2830*2030*2030 | 3220*2300*2600 | 3450*2510*2710 | 3800*2800*2710 |
Features:
This series equipment is used in the production of non-carbonated dirnk ,such as mineral water and purified water etc ,washing filling and capping integrated into one machine
features:
1.The suspending hottle-neckdamping design make the bottle stable during the high-speed moving conditions ,by changing a few parts it can meet the production of different types of bottles easily.
The new genernation of SS grabis adopted and the grabs have no contact ,with the area above the bottle's screw thread nozzles in the grad can guarantee the complete wash of the interior of the bottle.
2.The advanced graving filling technology used in this machine makes the filling quick ,steady and accurate.
3.Magnetic gorque is used for screw capping and the power of screw capping can be adjusted steplessly ,capping is realiable and do no harm to the caps
4.Advanced technologies such as human-machine inter face touch-screen and nPLC program control are adopted in this machine
5. All parts that have direct contact witht he wafe are made of high quality SS ,the criticed dlectrical components are from famous interantional compies such as Mitsubishi ,Omorn to the name a few.
