Mineral Water Filling Machine /machinery
Bottle Production WSHING-FILLING-CAPING 3-IN-1 UNIT :
Usage:
The line is mainly used for washing, filling sealing non carbon dioxide drink such as mineral water, pure water, non-gas wine drink and so on.
Characteristics:
It adopts hanging type conveying-bottle structure to make changing bottle model more convenient, faster and more east. The main machine adopts advanced PLC control technology. The key electric elements adopt international famous products.
model | CGF 14-12-5 | CGF 18-18-6 | CGF 24-24-8 | CGF 32-32-8 | ||
production(500/m/bottle/h) | 3000-5000 | 5000-6000 | 8000-10000 | 10000-12000 | ||
filler valves | 14 | 18 | 24 | 32 | ||
rinser grippers | 12 | 18 | 24 | 32 | ||
capper header | 5 | 6 | 8 | 10 | ||
suitable bottle shape | circular or square | |||||
bottle diameter(mm) | φ50-φ90 | |||||
bottle height(mm) | 150-310 | |||||
Compressed air pressure(MPa) | 0.3-0.7 | |||||
washing medium | aseptic water | |||||
washing water's pressure(MPa) | 0.25 | |||||
Total output (KW) | 2.2 | 3 | 4 | 6.2 | ||
oerall dimensions(mm) | 2350x1750x2250 | 2480x1960x2250 | 3010x2180x2400 | 4000x2200x2500 | ||
(weight kg) | 2500 | 2800 | 3500 | 6000 | ||
