Help CenterNew Condition Full Auto PET Bottle Blowing Machine China Factory
Related Products
-
SEMI AUTO Drinks Pet Bottle Blowing Machine PriceNegotiableMOQ: 1 Set -
ZG6000 Full Automatic Pet Bottle Blowing Machine/blow Molding Machine PriceNegotiableMOQ: 1 Set
-
Pet Bottle Blowing MachineNegotiableMOQ: 1 Set
-
Automatic Bottle Blowing MachineNegotiableMOQ: 1 Set
-
Semi-Automatic PET Bottle Blowing Machine / Stretch BLowerNegotiableMOQ: 1 Set
pet bottle blowing machine
Model:2L-4
item |
YCQ-2L-4 |
|
|
Bottle type specification
|
cavity |
4 |
output (PCS/HR) |
3500-4000 |
|
Max. volume (L) |
2L |
|
Bottle mouth maximum overall diameter (mm) |
28-38mm |
|
Bottle biggest diameter |
100mm |
|
Bottle maximum height |
330mm |
|
|
Power specifications
|
Light tube quantity |
32pcs |
Light tube power |
1.25kw |
|
Maximum heating power |
40kw |
|
All electric machine installation |
43kw |
|
Actual consumption |
21.5kw |
|
|
Air pressure specification
|
Work pressure |
7-9kg/cm2 |
Low-pressure gas consumption |
1600Ltr/min |
|
Blow bottle pressure |
25-35kg/cm2 |
|
Higher -pressure gas consumption |
3000 Ltr/min |
|
|
Frozen water specification
|
Work pressure |
5-6 kg/cm2 |
Temperature range |
10℃ |
|
Consumption |
8000kcal/hr |
|
Frozen water flow |
88Ltr/min |
|
|
Machine specification
|
Size of the machine |
4.5x1.6x1.9 (m) |
Weight of the machine |
3.5ton |
Machine Parts
| machine parts name | Brand | Original place |
| Pneumatic components | PARKER AND FESTO | USA AND GERMANY |
| turning cylinder | FESTO | Germany |
| high pressure air blowing valve | FESTO | Germany |
| low pressure work valve | PARKER | USA |
| PLC controller | MITSUBISHI | JAPAN |
| full computer screen | WINWIEW506L | TAIWAN |
| high pressure muffler | HENGLI | CHINA |
| Photoelectric switch | OMRON | JAPAN |
| Switching power | OMRON AND ZHENGTAI | JAPAN and CHINA |
| circuit breaker | ZHENTAI | CHINA |
| Air switch | OMRON | JAPAN |
| relay | OMRON | JAPAN |
| finger cylinder | JINGQI | TAIWAN |
Features
A. Stable performance with advanced PLC.
B. Conveying preforms automatically with conveyor.
C. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater.
D. High adjustability to enable the preheater to preheat preforms in shapes by adjusting the light tube and the length of the reflecting board in the preheating area, and eternal temperature in the preheater with an automatic thermostatic apparatus.
E. High safeties with security automatic-locking apparatus in each mechanical action, which will make the procedures turn into a state of safety in case of a breakdown in certain procedure.
F.No contamination and low noise with the air cylinder to drive the action instead of the oil pump.
G. Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.
H. Strong clamping force with high pressure and double crank links to lock the mold.
I. Two ways of operating: automatic and manual.
J. Safe, reliable, and unique design of the position of valve to make the air pressure diagram of the machine easier to understand.
K. Low cost, high efficiency, easy operation, easy maintenance, etc, with automatic technological process.
L. Contamination is avoided for the bottle body.
M. Ideal effect of the chilling with the chilling system.
N. Easy installation and starting
O.Low rejection rate: less than 0.3percent.
Machine Picture:
1. stretch film packaging to save container space
2. standard wooden case to protect machine's important part.
Company Information
Company Introduction
Zhangjiagang Jiazhou Machinery Co.,Ltd is a manufacturer in beverage machine field for about 15 years. She has her own factory which is founded in year of 1998. Her sale company Zhangjiagang Jiazhou Machinery Company Limited is set up in 2005. Jiazhou has entered into international trade in 2008, now is 7 years old on Alibaba.
Jiazhou has well cooperated with many clients in many countries and areas, such as Kenya, Nigeria, Malaysia, Vietnam, Bangladesh, Ghana, Madagascar, and Middle East Area. She also has popular market in China, received very good reputation.
Jiazhou shall make progress with clients and market. Her aim is to establish credibility and pursue specialized quality and service. Choose Jiazhou as business partner, you can get assured about the quality.
Our Service and Working Process
Pre- sales Phase: we have sales representative to communicate with our client to understand client needs and based on our experience, capacity to initiate the draft proposal for our client review. With the proposal review, analysis and improvement, we will finalize our proposal with our clients.
Production Phase: We have very strong filing machine business experience and downstream/upstream partnership. Under the criteria of customized quality, our good production scheduling will make sure our client filling machine will be delivered in time.
After-sales:We will documentation our client information for each sale and will continue effective communication even after deal. We will review the whole process to enhance our experience and make sure we can serve our client better and better.
