Full Automatic Wire Mesh Welded Machines Roll Mesh Welding Machines
US$ 25,000 - 60,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
JIAKE
Model Number:
JK
Payment & Shipping
Payment Methods:
Port of Shipment:
xingang
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2015 New Products of Electric Welded Mesh Machines Made in ChinaUS$ 25,000 - 60,000MOQ: 1 Set -
BWG 22-19 AUTOMATIC Electric Welded Wire Mesh MachineUS$ 10,000 - 100,000MOQ: 1 Set
-
Welded Wire Mesh Machine for Gabion MeshUS$ 15,000 - 60,000MOQ: 1 Set
-
Electric Welded Wire Mesh Machine for Gabion MeshUS$ 15,000 - 60,000MOQ: 1 Set
-
Best Price Gabion Welding Mesh Welded Wire Mesh MachineUS$ 15,000 - 60,000MOQ: 1 Set
Place of Origin
Hebei, China
Brand Name
JIAKE
Model Number
JK
Primary Voltage
380V
Rated Duty Cycle
10
Rated Capacity
40KVA*4
Dimensions
3050*1800*1400mm
Usage
weld construction mesh
After-sales Service Provided
Engineers available to service machinery overseas
Full Automatic Wire Mesh Welded Machines Roll Mesh Welding Machines
Product Description
Electric welded wire mesh machines description:
1. line wire and cross wire in coil, automatically feed
2. mesh size and width could be easily set according to client's needs.
3. easy to operate and maintainance.
Technical Parameter
Electric welded wire mesh machines parameter:
| Model | JK-DNW-1 | JK-DNW-2 | JK-DNW-3 |
| wire diameter | 0.4mm.65mm | 0.65mm-1.8mm | 1.0mm-2.2mm |
| mesh width | 914.4mm, 1000mm | 1219.2mm, 1524mm | 1219.2mm, 1524mm, 1828.8mm, 2133.6mm |
| aperture/pitch | 6.35mm-12.7mm | 12.7mm-101.6mm | 25.4mm-101.6mm |
| motor | 2.2kw | 2.2kw | 2.2kw; 4.0kw |
| welding speed | max 75 cross wires/min | max 120cross wires/min | max 80cross wires/min |
| welding transformer capacity | 50KVA*3 | 60KVA*4; 60KVA*5 | 60KVA*4; 60KVA*5;60KVA*6;60KVA*7 |
| Dimension | 2.3m*1.3m*1.4m | 2.5m*1.3m*1.4m 2.9m*1.3m*1.4m | 2.5m*1.3m*1.4m 2.9m*1.3m*1.4m |
| weight | 1.5T | 2.0T; 2.5T | 2.0T 2.5T 3.0T 3.5T |
| voltage | 3phase; 380V, 50hz, or according to client's voltage | 3phase; 380V, 50hz, or according to client's voltage | 3phase; 380V, 50hz, or according to client's voltage |
Auxiliary Equipments
Auxiliary machine for electric welded mesh machine
| Auxiliary machine | Pictures |
|
wire rolling machine 1set and wire pay-off 3sets; and numbers of plastic rollers cording to aperture
Application:roll the wire from big coils to plastic rollers
suitable wire diameter less than 1.2mm |
|
|
Braket for line wires 1set
Application: bear the plastic rollers with line wire
suitable wire diameter less than 1.2mm
|
|
|
wire pay-off whole set
Application: loading the line wires |
|
| mesh repairing machine and repairing table | |
Finished Products
