2015 New products of electric welded mesh machines
Description of electric welded mesh machines:
- Wire feeding : both line wire and cross wire was feeding automatically from wire coils.
- Raw material: low-carbon steel wire.
- Easy to operate and electro-magnetism adjustable speed for welding.
- Width: could be set according to customers’ requirement.
Parameter of electric welded mesh machines:
Model |
JK-DNW-2 |
JK-DNW-3 |
Wire diameter |
0.65-1.8mm |
1.0-2.2mm |
Mesh width |
1524mm(5’) |
2133.6mm(7’) |
Aperture /pitch/cell |
25.4-101.6mm(1’-4”) |
25.4-101.6mm(1”-4”) |
Welding spot |
30pcs (2”cell) |
42pcs(2” cell) |
Motor |
2.2kw |
4.0kw |
Welded transformer capacity |
60KVA*5 |
60KVA*7 |
Welding speed |
120 cross wires/min |
80 cross wires/min |
Measurement |
2.4m*1.3m*1.4m |
2.9m*1.3m*1.4m |
Weight |
2.5T |
3.5T |
Voltage |
380V 50HZ 3phase |
|
Power transformer needed |
120KVA 120mm²aluminum wire ≤100m between machines and transformer |
|
Auxiliary of electric welded mesh machines:
Electrical control cabinet |
|
Wire pay-off whole set |
|
Repairing machines 1set |
|
Repairing table 1set |
|
Electric scissor |
1set |
1.Wire Mesh Welding Machines JK-RM-2500B for reinforcing mesh or steel bar mesh
|
|
2. Wire Mesh Welding Machines JK-FM-2500S for fence mesh or construction mesh
|
|
3. Full Automatic Wire Mesh Welding Machine JK-AC-1200S for construction mesh or poultry cage mesh
|
|
4. electric welded mesh machines for construction mesh
|
|
All our machines could be customized, please contact us for much more details
Inquiry now, and we will reply ASAP and welcome to visit our factory!
