Bar-mat Reinforcement welding machines JK-RM-2500B
Bar-mat Reinforcement welding machines Function Characteristics:
1.synchronous control.
2.welding time and separate welding are controlled by computer.
3.Windows operation system, making operation more intelligence.
4.Mesh drawing system is controlled by servo- motor., which improves the precision of mesh opening size.
5.the line wire and cross wire spacing are adjustable.
Bar-mat Reinforcement Application:
Construction reinforcing mesh, highway cement concrete pavement using mesh reinforcement , bridge deck pavement using mesh reinforcements, sprayed concrete with mesh reinforcement, tunnel lining with steel mesh
Bar-mat Reinforcement Welding Machine Main Parameters:
Wire diameter: 5-12mm
Line wire spacing: 100-300mm
Cross wire spacing: 50-300mm
Max width: 2500mm
Welding No.: 24
Power: 380V 50HZ
Rated capacity: 150KVA*12
Motor power: 5.5kw
Line wire feeding: pre-straight and pre-cut
Cross wire feeding: pre-straight and pre-cut
Welding speed: 45-65 times/min
Dimension: 20m*3.6m*2.5m
Weight:9T
A: Pre-sale service; plant layout design, technical consulting, feasibility studies, cost and ROI analysis;
B: sales services: installation and commissioning, operator training, electrician and mechanic training;
1.Equipment installation and commissioning: assist and guide customer coordinate the equipment layout according to the actual situation, make reasonable arrangements for the overall planing of the installation location. Assigned technician to provide equipment installation, operation, ancillary facilities, production, repair, maintenance services and answer the relevant questions.
2.Training operation and maintenance personnel: our company will provide training of the operation and maintenance personnel according to customer’s requirement.
C: after-sale service; supply spare parts and provide after-sale services
1.supply of spare parts: keep records for each customer, provide long-term supply of spare parts, and send it to customers hand with the fastest speed according to customers’ requirement.
2.Unexpected emergency repair service: once the equipment have malfunction, and the user unable to rule out, we will arrange technician to the user factory in the soonest time, solve the trouble and resume production in time.
Hebei Jiake Welding Equipment Co., Ltd. founded in 2000, located at the junction of Beijing, Tianjin and Shijiazhuang, Anping County, which is famous as “Hometown of wire mesh” in China, is a professional manufacturer for wire mesh machineries. The company has been developing smoothly and quickly and it has more than 100 employees. And the company has own wire mesh machineries and several pilot plants with strong technical force and advanced production and checkout equipments.
Our main products: 3D panel production line, steel bar mesh welding machine, CNC fence mesh welding equipment , 3D panel wire mesh machine (Bevel inserting combination joint machine), welding equipment of mine sieve mesh, chicken cage mesh welding machine, electric welded mesh machine and so on.
