Help CenterBest Price Gabion Welding Mesh Welded Wire Mesh Machine
Related Products
-
Hebei JIAKE Electric Welded Mesh MachineUS$ 10,000 - 100,000MOQ: 1 Set -
Full Automatic Electric Wire Mesh Welding Machine (in Roll)US$ 10,000 - 100,000MOQ: 1 Set
-
Metal Wire Electric Welded Mesh MachineUS$ 10,000 - 45,000MOQ: 1 Set
-
Electric Rolling Welded Wire Mesh MachineUS$ 10,000 - 50,000MOQ: 1 Set
-
Automatic Feeding Electric Welded Wire Mesh MachineUS$ 10,000 - 100,000MOQ: 1 Set
Specifications
1electric welded wire mesh machine2 mesh hole:12.7mm-101.6mm
3 diameter of the wire:0.63mm-2.0mm
machine size:2.6m*1.7m*1.3m
electric welded wire mesh machine
electric welded wire mesh machine
electric welded wire mesh machine
Main function
The electric welded wire mesh machine adopts computer and PLC control technique,both longitude wire and cross wire was feeding from wire coils automatically.the raw material is applicable for low-carbon steel wire or stainless steel wire.the mesh size is precise and machine can be set the width of length according to customers' requipment.
electric welded wire mesh machine
Main parameter
the welding speed can reach 120 rows per minute
electric welded wire mesh machine
Application
widely used in industry, agriculture, breeding, construction, transportation, mining, etc.
Guarantee time
1years after install but should be within 18 months of theB/L date
esh (mm) |
Width (mm) |
Wire Diameter (mm) |
Production Length per Roll (mm) |
Welded Speed |
Energy Consumption |
Overall Dimension(mm) |
12.7-101.6 (1/2"-4") |
914.4-1219.2 |
Dia.0.63-Dia.2 |
120 (400') |
90-120 |
380V |
2600x1700x1350 |
Mesh (mm) |
Width (mm) |
Wire Diameter (mm) |
Production Length per Roll (mm) |
Welded Speed |
Energy Consumption |
Overall Dimension(mm) |
25.4-152.4 (1"-6") |
1219.2,1524,1828.8 |
Dia.1.07-Dia.2 |
91.4m (300') |
50-80 |
380V; |
3350x1800x1400 |
Mesh (mm) |
Width (mm) |
Wire Diameter (mm) |
Production Length per Roll (mm) |
Welded Speed |
Energy Consumption |
Overall Dimension(mm) |
6.35-12.7 (1/4"-1/2") |
1219.2-1828.8 (48"-60") |
Dia.0.74-Dia.1.07 |
120m (400') |
70-100 |
380V; |
3050x1900x1750 |
Mesh (mm) |
Width (mm) |
Wire Diameter (mm) |
Production Length per Roll (mm) |
Welded Speed |
Energy Consumption |
Overall Dimension(mm) |
6.35-12.7 (1/4"-1/2") |
914.4-1219.2 (12"-48") |
Dia.0.45-Dia.1.07 |
120m (400') |
90-120 |
380V; |
2350x1820x1700 |
