Specifications
automatic feeding electric welded wire mesh machinehigh speed and stable function
highly automatic
very accurate
CE
automatic feeding electric welded wire mesh machine
1.It is made up of main welding machine, electrical control cabinet, repairing table, repairing machine, bracket for longitude wires, wire rolling machine and plastic rollers.
2.Both longitude wire and cross wire are fed from wire coils automatically.
3.It has advantage such as design reasonable, low noise, more stable, easier to operate.
4.The mesh size is precise and the machine can set the width of length according to customers’ requirements.
automatic feeding electric welded wire mesh machine
Model |
JK-DNW-2 |
Mesh width |
1219.2mm,1524mm (4feet, 5feet) |
Aperture/Pitch |
12.7mm-101.6mm |
Wire Diameter |
0.65mm-1.8mm |
Voltage |
3-phase,380V,50Hz or according to client’s voltage |
Motor |
2.2KW |
Welding Speed |
≤120rows/min |
Measurement of Machine |
2.5m*1.3m*1.4m 2.9m*1.3m*1.4m |
Weight |
2.0T, 2.5T |
Welded Transformer Capacity |
60kva*4; 60kva*5 |
Other models:
Model |
JK-DNW-1 |
JK-DNW-3 |
Mesh width |
914.4mm,1000mm |
1219.2mm,1524mm, 1828.8mm,2133.6mm (4feet,5feet,6feet,7feet) |
Aperture/Pitch |
6.35mm-12.7mm |
25.4mm-101.6mm |
Wire Diameter |
0.4mm-0.65mm |
1.0mm-2.2mm |
Voltage |
3-phase,380V,50Hz or according to client’s voltage |
3-phase,380V,50Hz or according to client’s voltage |
Motor |
2.2KW |
2.2KW,4.0KW |
Welding Speed |
≤75 rows/min |
≤80 rows/min |
Measurement of Machine |
2.3m*1.3m*1.4m |
2.5m*1.3m*1.4m 2.9m*1.3m*1.4m |
Weight |
1.5T |
2.0T, 2.5T,3.0T, 3.5T |
Welded Transformer Capacity |
50kva*3 |
60kva*4,60kva*5,60kva*6,60kva*7 |
automatic feeding electric welded wire mesh machine
automatic feeding electric welded wire mesh machine
