Help CenterCT88KA-63 Steam Forging Hammer Reform 2.5Tons
Related Products
-
C88K Electro Hidráulica Die Forjamento Martelo 0.75-6.5TonsNegotiableMOQ: 1 Set -
Kìm / Kìm / Wrenches Rèn / Chết Giả Múa 31.5kJNegotiableMOQ: 1 Set
-
C88K-100 Chinese Forging Hammer/CNC Fully Hydraulic Forging Hammer C88K-63(2.5TONS)NegotiableMOQ: 1 Set
-
D46 Cross Wedge Roll/D46 Rolo de Cunha de Cruz/D46 Chéo Chéo Cuộn/D46 KreuzkeilrolleNegotiableMOQ: 1 Set
-
ZGD Automatic Forging RollNegotiableMOQ: 1 Set
Main features:
01) Program control, numerical input, simple operate;
02) High integrated hydraulic control system, accumulator fixed directly on main valve block without any pipe connecting, improve hydraulic system efficiency and easy for maintenance
03) Advanced taper valve control, fast response, good sealing and not easy to inner leakage;
04) High response speed and high reliable redundancy design;
05) Hydraulic driving system and power system assembled on top separately, no hydraulic pump station on floor;
06) Touch screen man-machine interface and automatic malfunction diagnosis and alarm, easy for machine operation and maintenance;
07) Safety design for inner accumulator and pipeline assembly;
08) Swaying combine oil cylinder and thin piston rod flexible design;
09) High and low pressure double anti-leakage design;
10) Long ram structure can improve working accuracy;
11) Striking energy and steps can be preset at will, no surplus striking energy can reduce striking noise and improve die life;
12) Slow up and down in the case of releasing hydraulic system pressure to make die changing safety;
13) Ram buffer is inner hydraulic buffer, to make sure safety and effective;
Optional machines:
Special designed die automatic lubrication, blank convey system, ejector and scale removing system are for customer to choose. They can be linked to hammer through program to realize die lubrication locating, timing, quantifying control, to improve its productivity and reduce labor intensity.
Main technical parameter:
item |
unit |
CT88KA- 25 |
CT88KA- 50 |
CT88KA- 80 |
CT88KA- 125 |
CT88KA- 200 |
CT88KA- 250 |
CT88KA- 320 |
CT88KA- 400 |
CT88KA- 450 |
Striking energy |
KJ |
25 |
50 |
80 |
125 |
200 |
250 |
320 |
400 |
450 |
|
Max. Striking frequency |
Min-1 |
90 |
80 |
70 |
60 |
55 |
50 |
45 |
40 |
40 |
Ram weight |
Kg |
1750 |
3400 |
5100 |
8000 |
10500 |
11500 |
13000 |
16000 |
18000 |
Dropping weight |
Kg |
2100 |
4100 |
6100 |
9500 |
12500 |
15000 |
17000 |
20000 |
22000 |
|
Main motor power |
Kw |
55 |
2X55 |
2X90 |
4X55 |
4X90 |
4X90 |
4X110 |
4X132 |
4X132 |
