Home > Transportation > Forklifts & Parts > Forklift > China Suppliers 1.5 Ton Electric Forklift Truck CE Approved With Battery AC Motor /China Mini Forklift Truck
China Suppliers 1.5 Ton Electric Forklift Truck CE Approved With Battery AC Motor /China Mini Forklift Truck
US$ 12,000 - 13,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
OEM
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China 2.0 Ton Electric Forklift Truck CE Approved With Battery AC MotorUS$ 13,000 - 15,000MOQ: 1 Set -
Hot Sale 1.8 Ton Electric Forklift Truck CE Approved With Battery AC Motor /China Mini Forklift TruckUS$ 12,000 - 13,000MOQ: 1 Set
-
10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 KgUS$ 100 - 100,000MOQ: 1 Set
-
5 Ton Capacity Diesel Forklift,big Capacity Forklift Diesel 5000kgUS$ 100 - 100,000MOQ: 1 Set
-
China New ac Motor Electric Forklift FB30/china 3t Forklift TruckUS$ 17,000 - 25,000MOQ: 1 Set
Condition
New
Place of Origin
Jiangsu, China
Brand Name
OEM
Model Number
FB15
Type
Powered Pallet Truck
Power Souce
AC Motor
Rated Loading Capacity
1500kg
Max. Lifting Height
3000mm
Min. Lifting Height
135mm
Fork Length
920mm
Fork Width
100mm
Overall Dimensions
2140*1080*2015mm
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Goods description of DC electric forklift FB15
Forklift truck is widely used in station, port, airport, factory, warehouse or others production departments.It is the high efficient equipment for loading and unloading, stacking, Short-Distance transport.
Features:
1). Streamlined exterior and beautiful appearance
2). The wide-view mast improves the efficiency and safety of operations
3). Scientific ergonomic designs ensure the comfort of driving
4). Reliable separate excitation motor
5). SME/ZAPI/Curtis/GE electronic controller
6). High-capacity battery
Standard specifications for 1.5ton electric forklift
| Model | FB15 | |||
| Load Capactity | kg | 1500 | ||
| Load Center | mm | 500 | ||
| Motor Type | Battery | |||
| Driving Type | Sit Down Driving Type | |||
| Tire Type | Pneumatic | |||
| Max. Lift Height | mm | 3000 | ||
| Free Lift Height | mm | 135 | ||
| Fork Size (L×W×T) | mm | 920×100×35 | ||
| Mast Tilt Angle (Fwd/Bwd) | deg | 6/12 | ||
| Front Overhang | mm | 400 | ||
| Overall Dimensions | Length to Fork Face | mm | 2140 | |
| Width | mm | 1080 | ||
| Mast Lowered Height | mm | 2015 | ||
| Mast Extended Height | mm | 3984 | ||
| Overhead Guard Height | mm | 2130 | ||
| Min. Turning Radius | mm | 1956 | ||
| Min. Right Angle Aisle Width | 1000×1200 crossways | mm | 3556 | |
| 800×1200 lengthways | mm | 3756 | ||
| Ground Clearance | mm | 110 | ||
| Lifting Speed | Unladed | mm/s | 400 | |
| Laded | mm/s | 240 | ||
| Traveling Speed | Unladed | km/h | 12 | |
| Laded | km/h | 11 | ||
| Max. Gradeability | % | 15 | ||
| Deadweight (including battery) | kg | 2950 | ||
| Tire | Front/Rear | pcs | 2/2 | |
| Size | Front | 6.50-10-10 PR | ||
| Rear | 5.00-8-8 PR | |||
| Wheelbase | mm | 1380 | ||
| Tread | Front | mm | 890 | |
| Rear | mm | 920 | ||
| Battery | Voltage/Capacity | V/Ah | 48/450 | |
| Electric Motor | Drive Motor | kw | 6.5 | |
| Lifting Motor | kw | 8.2 | ||
| Electronic Controller | DC Controller (SME / ZAPI / Curtis / GE) | |||
| Working Pressure | Mpa | 14.5 | ||
