Home > Transportation > Forklifts & Parts > Forklift > 10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg

10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg

10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg thumbnail-1
10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg thumbnail-2
10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg thumbnail-3
10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg thumbnail-4
10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg thumbnail-5
10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg photo-1
10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg photo-2
10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg photo-3
10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg photo-4
10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg photo-5
US$ 100 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
Nantong Jakarta
Contact Supplier Request Quote Chat Now
Nantong Jakarta Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name Nantong Jakarta
Model Number CPCD100
Type Powered Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 10000kg
Max. Lifting Height 4330mm
Min. Lifting Height 3000mm
Fork Length 5480mm
Fork Width 2230mm
Overall Dimensions 5480*2230
Certification ISO90001,ISO14001
After-sales Service Provided Engineers available to service machinery overseas



  Introduction

       The company now owns more than 100 models of self-owned forklift products in 72 types. Comprehensive performance of those products is leading in China and advanced in the World. Holistic marketing network is established with complete service system inside and outside China. The company’s products have been sold to more than 60 countries and regions all over the world in the meantime, eg. Turkey, Russia, UAE, Singapore, Indonesia etc.



10 ton diesel forklift,diesel forklift 10000kg 10 ton diesel forklift,diesel forklift 10000kg 10 ton diesel forklift,diesel forklift 10000kg

  Forklift Specification





Load center distance

mm

600

Lifting height

mm

3000

Maximum height at work

mm

4330

 Mast tilt angle(Forwards/Backwards)

6/12

 Hold under mast(min)

mm

245

 Turning radius(min)

mm

3900

Travelling speed (max)

Unloaded

Km/h

26

Loaded

24

Lifting speed (max)

Unloaded

mm/s

290

Loaded

350

Lowering speeds(max)

mm/s

≤600

Gradeability under full load (max)

%

20

Dimensions

Length

Overall length

mm

5480

Length (without fork)

4260

Width

2230

Height

Closed mast height

2850

Overhead guard height

2600

Wheelbase

mm

2800

Wheel tread

Front

mm

1600

Rear

1700

Tire

Front

-

9.00-20-14PR

Rear

-

9.00-20-14PR

Engine

Model

-

  Xichai 6110

Displacement

L

7.127

Rated power

Kw

83

Revolution at rated power

Rpm

2000

Maximum torque

Nm

450

Revolution at maximum torque

rpm

1450

 Fuel tank capacity

L

150

Fork size(LxWxT)

mm

1220×175×80

Total weight

Kg

12500







Product picture

10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg



Photo details

10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg

10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg



Engine manufacture Engine model

Rated power /

Revolution at rated power

 Kw/rpm

Rated torque /

 Revolution at

rated torque

N.m/rpm

Engine displacement

L

 Fuel type Adaptive forklift Origin
XINCHAI C490BPG 40/2650 160/1800 2.67 Diesel 2~3.5T Chinese
XINCHAI A490BPG 40/2650 160/1800 2.67 Diesel 2~3.5T Chinese
XINCHAI A495BPG 42/2650 174/1800 2.98 Diesel 3~3.5T Chinese
DACHAI (DEUTZ) CA498 45/2500 190/1800 3.16 Diesel 2~3.5T Chinese
JMC JX493 39/2500 165/1800 2.77 Diesel 2~3.5T Chinese
ISUZU C240PKJ 34.5/2500 139/2500 2.4 Diesel 2~3.5T Japanese
YANMAR 4TNE98 42/2300 177.6/1700 3.319 Diesel 2~3.5T Japanese
NISSAN K25 37.4/2300 176.5/1600 2.488 Gasoline 2~3.5 T Japanese
LUOTUO LR4B3 57/2200 270/1560 4.33 Diesel 4~5T Chinese
XICHAI CA4110 61/2200 305/1500 4.75 Diesel 4~5T Chinese
XINCHAI 498BPG 45/2500 193/1800 3.16 Diesel 4T Chinese
XINCHAI 4D35G 48/2200 230/1600 3.32 Diesel 4~5T Chinese
CHAOCHAI CY6102 81/2000 353/1600 5.785 Diesel 5~10T Chinese
ISUZU 6BG1 82.4/2000 416/1500 6.49 Diesel 5~10T Japanese
XICHAI CA6110 83/2000 450/1500 7.127 Diesel 5~10T Chinese
PERKINS 1104D 55.9/2200 265/1700 4.4 Diesel 4~5T English
BAIYANG 491 41/2800 161/1800 2.7 Gasoline 2~2.5T Chinese
YUCHAI YC6B125 92/2200 460/1600 6.871 Diesel 10T Chinese
XICHAI CA6110/125ZT 117/2200 570/1600 7.127 Diesel 12T Chinese
YUCHAI YC6A180Z 140/2300 670/1600 7.255 Diesel 16T Chinese



Forklift Attachments Conents





Photo accessories

10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg





Delivery photos

10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg

Factory Photos

10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg

10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg10 Ton Capacity Diesel Forklift,Big Capacity Forklift Diesel 1000 Kg
