2.5 Ton Electric Forklift Truck CE Approved With Battery AC Motor

2.5 Ton Electric Forklift Truck CE Approved With Battery AC Motor thumbnail-1
2.5 Ton Electric Forklift Truck CE Approved With Battery AC Motor photo-1
US$ 13,000 - 14,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
OEM
Contact Supplier Request Quote Chat Now
Nantong Jakarta Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name OEM
Model Number FB25
Type Powered Pallet Truck
Power Souce AC Motor
Rated Loading Capacity 2500kg
Max. Lifting Height 3000mm
Min. Lifting Height 160mm
Fork Length 1070mm
Fork Width 122mm
Overall Dimensions 3525*1180*2015mm
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Goods description of DC electric forklift FB25

Forklift truck is widely used in station, port, airport, factory, warehouse or others production departments.It is the high efficient equipment for loading and unloading, stacking, Short-Distance transport.



Features:



1). Streamlined exterior and beautiful appearance

2). The wide-view mast improves the efficiency and safety of operations

3). Scientific ergonomic designs ensure the comfort of driving

4). Reliable separate excitation motor

5). SME/ZAPI/Curtis/GE electronic controller

6). High-capacity battery2.5 ton electric forklift truck CE approved with battery AC motor2.5 ton electric forklift truck CE approved with battery AC motor

Standard specifications for 2.5ton electric forklift

Characteristics 1 Model   FB25
2 Load capacity kg 2500
3 Load center mm 500
4 Power type   Battery
5 Operation type   Seater
6 Tyre type front/rear   pneumatic tire
7 Wheel front/rear   2X/2
 Dimensions 8 Lifting height mm 3000
9 Free lift height mm 160
10 Fork size            L*W*T deg 1070*122*40
11 Tilt angle    front/rear mm 6/12
12 Overall length(without fork) mm 2285
13 Overall width mm 1150
14 Mast height(lower) mm 1995
15 Mast height(extended) mm 4030
16 Height of overhead guard mm 2095
17 Turning radius(outside) mm 2000
18 Distance(fork face to front axle) mm 445
19 Min.right angle working aisle mm 1935
Performance 20 Speed Travel  load km/h 13
speed unload km/h 14.5
21 Up load mm/s 240
unload mm/s 450
22 Gradeability load % 12.5
Weight 23 Service weight (with standard battery) kg 3820
24 Weight  distribution load front kg 5425
rear kg 895
25 unload front kg 1425
rear kg 2395
Brake and Tyre 26 Wheel number front/rear   2/2
27 specification front   21*8-9-16PR
28 rear   18*7-8-14PR
29 Wheelbase   mm 1400
30 Tread front/raer mm 955/950
31 Ground  lowest(mast) mm 110
clearance frame mm 115
32 Brake service brake   Hydraulic booster
parking brake    Mechanical
Engine and Transmission 33 Battery voltage/capacity V/AH/5hr 48V-450
weight(standard) kg 945
24 Electric  motor drive motor kw/60min 6.5
35 hydraulic drive motor kw/15min 8.6
36 steering motor kw/60min 0.8
37  Control Method Electric drive
38 Operation pressure hydraulic system pressure kg/cm2 175

  More details

2.5 ton electric forklift truck CE approved with battery AC motor

2.5 ton electric forklift truck CE approved with battery AC motor2.5 ton electric forklift truck CE approved with battery AC motor2.5 ton electric forklift truck CE approved with battery AC motor
