Sell China Brand High Quality EDM Brass Wire

Sell China Brand High Quality EDM Brass Wire photo-1
Sell China Brand High Quality EDM Brass Wire photo-2
Sell China Brand High Quality EDM Brass Wire photo-3
Sell China Brand High Quality EDM Brass Wire photo-4
US$ 8.25 - 9.2 MOQ: 300 Kilograms
Key Specifications
Get Latest Price
Brand Name:
BASHAN
Place of Origin:
China
Model Number:
BSH30**
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin,qingdao
Delivery Detail:
7 days
Brand Name BASHAN
Place of Origin China
Model Number BSH30**
Type Brass Wire
Application used on low speed wire cutting machines like Agie-charmilles, Sodick, Mitsubishi, Makino
Ultimate Strength (≥ MPa) 380-420
Alloy Or Not Is Alloy
Grade BSH1503
Wire Gauge 0.3mm
Cu (Min) 66.4%-83%

Features of China Brand High Quality EDM Brass Wire for Sale.

1.High dimensional accuracy.
2.Diameter tolerance is kept to +0 ~ -0.002mm and circularity within 0.001mm.
3.Outstanding straightness.
4.We test each spool for curling and torsion and pride ourselves on the stable automatic wire threading performance or our product.
5.Stable mechanical properties.
6.Tensil strength, elongation, breaking load, etc. are checked with automatic measuring equipment to ensure stable quality.
7.Ultra-smooth surface.

Product Details of China Brand High Quality EDM Brass Wire for Sale.


Product Description
 The description of China Brand High Quality EDM Brass Wire for Sale.

1. Grade: Cu/Zn
2.Model Number:0.1mm.
3. Alloy Or Not:Is Alloy
4. Place of Origin:henan,China
5. Certification: Passed ISO9001:2008 quality certificate
Passed ISO/TS16949:2009 certificate
Passed GJB9001A-2001 military quality certificate.
6.Brand Name:Bashan


 China Brand High Quality EDM Brass Wire for Sale.

Product Name
China Brand High Quality EDM Brass Wire for Sale
Material
 Material : CuZn35,CuZn37,CuZn40
 Wire diameter
0.25mm
Weight/Spool
Weight/Spool:3kg/5kg/7kg/15kg/20kg
Tensile strength:
above 980Mpa
Packing
Vacuum packing, sealed with PVC cellephane, moisture proof, quakeproof, and corrosion resistance.
Used
used on low speed wire cutting machines like Agie-charmilles, Sodick, Mitsubishi, Makino

The Specification of China Brand High Quality EDM Brass Wire for Sale.

Condition
Diameter(mm)
Tolerance(mm)
Tensile Strength (N/mm²)
Type of Spool
(Standard Weight)
       Hard
0.10
±0.001
≥980
DIN125(3kg,3.5kg
0.15
±0.001
≥980
0.20
±0.001
≥980
DIN125(3kg,3.5kg)

p5(5kg)

DIN160(7kg,8kg)

DIN200(15kg,16kg)
0.25
±0.001
≥980
0.30
±0.001
≥980
    Semi-hard
0.25
±0.001
480~520
0.30
±0.001
         Soft
0.25
±0.001
380~420
0.30
±0.001

Because the space is limited , We Only listed a few specifications of wire thread inserts . if you want to learn more,Welcome to  contact me any time

Reliable Raw Materials

Good and reliable raw material is the most important factor of producing excellent fine stainless steel wire. Bashan company use good raw materials from well-known iron manufacturers at home and abroad. Ugitech in France, Hikari Works in Japan, Tisco in China, D&B Special Steel in China, Ruipu in China, etc.
