High Purity 0.25mm EDM Brass Wire

High Purity 0.25mm EDM Brass Wire thumbnail-1
High Purity 0.25mm EDM Brass Wire thumbnail-2
High Purity 0.25mm EDM Brass Wire thumbnail-3
High Purity 0.25mm EDM Brass Wire photo-1
High Purity 0.25mm EDM Brass Wire photo-2
High Purity 0.25mm EDM Brass Wire photo-3
US$ 8.25 - 9.2 MOQ: 300 Kilograms
Key Specifications
Get Latest Price
Brand Name:
BASHAN
Place of Origin:
China
Model Number:
BSS30**
Contact Supplier Request Quote Chat Now
Xinxiang Bashan Aero Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin,qingdao
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BASHAN
Place of Origin China
Model Number BSS30**
Type Brass Wire
Application used on low speed wire cutting machines like Agie-charmilles, Sodick, Mitsubishi, Makino
Ultimate Strength (≥ MPa) 380-420
Alloy Or Not Is Alloy
Grade BSH1003
Wire Gauge 0.25mm
Cu (Min) 66.4%-83%
The description of High Purity 0.25mm EDM brass Wire

  1. Grade: Cu/Zn
    2.Model Number:0.1mm.
    3. Alloy Or Not:Is Alloy
    4. Place of Origin:henan,China
    5. Certification: Passed ISO9001:2008 quality certificate
    Passed ISO/TS16949:2009 certificate
    Passed GJB9001A-2001 military quality certificate.
    6.Brand Name:Bashan

 High Purity 0.25mm EDM brass Wire

Product Name
High Purity 0.25mm EDM brass Wire
Material
 Material : CuZn35,CuZn37,CuZn40
 Wire diameter
0.25mm
Weight/Spool
Weight/Spool:3kg/5kg/7kg/15kg/20kg
Tensile strength:
above 980Mpa
Packing
Vacuum packing, sealed with PVC cellephane, moisture proof, quakeproof, and corrosion resistance.
Used
used on low speed wire cutting machines like Agie-charmilles, Sodick, Mitsubishi, Makino

The Specification of High Purity 0.25mm EDM brass Wire

Condition
Diameter(mm)
Tolerance(mm)
Tensile Strength (N/mm²)
Type of Spool
(Standard Weight)
       Hard
0.10
±0.001
≥980
DIN125(3kg,3.5kg
0.15
±0.001
≥980
0.20
±0.001
≥980
DIN125(3kg,3.5kg)

p5(5kg)

DIN160(7kg,8kg)

DIN200(15kg,16kg)
0.25
±0.001
≥980
0.30
±0.001
≥980
    Semi-hard
0.25
±0.001
480~520
0.30
±0.001
         Soft
0.25
±0.001
380~420
0.30
±0.001


Product Tags: EDM Brass Wire , EDM copper Wire , EDM Brass cable
