Mini Panel 11dBi 5.8GHz FPV Video Antenna
Applications:
* 5.8GHz Band
* Wireless Video Links
* Wireless Security Cameras
* Wireless Video Transmitters
* Wireless Security Systems
Specifications:
Frequency: 5600 - 5900MHz
Gain: 11 dBi
Horizontal Beam: 45 degrees
Vertical Beam: 30 degrees
VSWR: < 2.0
Input Impedance: 50(Ω)
Polarization: Vertical Polarization
Maximum Power: 50(W)
Connector: SMA or RP-SMA
Size: 88x70x120mm
Weight: 50g
Application Examples:
1) Connect with a wireless portable receiver / monitor to increase the wireless video performance.
2) Connect with a FPV video receiver on the ground station for long range wireless system.
Contact us for more FPV antennas!
