Original NEW TS832 VTX RC832 VRX Combo With RaceBand 5.8GHz 40CH 600mW FPV Transmitter and Receiver
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Use:
Other, Vehicles & Remote Control Toys
Place of Origin:
Guangdong, China
Brand Name:
Correa
Payment & Shipping
Payment Methods:
Port of Shipment:
Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TS5823L 5.8GHz 40CH 200mW 5G8 Mini FPV TransmitterNegotiableMOQ: 1 Piece -
FPV System FR632 Diversity 5.8GHz 40CH Auto Scan LCD A/V ReceiverNegotiableMOQ: 1 Piece
-
5.8GHz Wireless Auto Scan 40CH Race Band 5.8 FPV Diversity Receiver FR632NegotiableMOQ: 1 Piece
-
FPV Race Band 5.8GHz 40 Channels 600mW VTX Fatshark ImmersionRC Compatible 5.8 Video Transmitter TS832NegotiableMOQ: 1 Set
-
TS832 5.8GHz 40 Channel 5G8 Long Range Wireless Video Tx 5.8GHz 600mW FPV TransmitterUS$ 10 - 15MOQ: 1 Piece
Use
Other, Vehicles & Remote Control Toys
Place of Origin
Guangdong, China
Brand Name
Correa
Model Number
TS832+RC832
Original NEW TS832 VTX RC832 VRX Combo with RaceBand 5.8GHz 40CH 600mW FPV Transmitter and Receiver
Transmitter specs:
Power input: 7.4-16V (3S Lipoly suggested)
Transmitting power: 600mW
Antenna gain: 2dbm
Working current: 220mA at 12V
Video bandwidth: 8Mhz
Audio bandwidth : 6.5Mhz
Weight: 21g
Dimension: 54x 32x 10mm(excluding antenna)
Frequency and Channel table:
note: NEW version and upgrade to 40 channels.
Receiver specs:
Sensitivity: Power Input: DC 12V
Working Current: 200mA max
Antenna Impedance: 50Ω
Video Impedance: 75Ω
Video Format: NTSC/PAL auto
Dimension: 80x 65 x15mm
Weight: about 85g
