Specifications
Sand cement brick machine manufacturer in Shandong / brick machine supplier (Hongfa)1ISO CE SGS2strong qiality3newest techologySand cement brick machine manufacturer in Shandong / brick machine supplier ( Hongfa )
( QT4-26 / QT4-20 / QT4-15 / QT5-15 / QT6-15 / QT8-15 / QT10-15 / QT12-15 )
Shandong Hongfa as the top manufacturer for aerated autoclaved concrete block making machine (AAC) , concrete bricks&blocks making machine with over 20 years experience has four branches in China , We win customers at home and abroad by strong quality and unbeatable service with competitive price , we have exported our products toover 120 countries .
We win customers by strong quality , unbeatable service and competitive price
Let me show you QT8-15D type :
Breif information:
1.The machine can serve several purposes and can produce pavement bricks, riverside bricks, revetment bricks ,square bricks ,grassed bricks and so on with different moulds.
2.Low frequency in feeding material, high frequency vibration. Platform vibrating works together with mould, So that the concrete can be fully fluidified and exhausted in two or three seconds to reach the high density.
3.The advanced technique of hydraulic-controlled proportion can handle the oil press and amount of the system freely,therefore ,different materials can be able to produce the high quality products.
4.All the procedures are operated by PLC and equipment with out and in date device to realize person-machine conversation. Control system also including the advanced safe logical system and fault diagnosis system.
QT8-15D Sand cement brick machine manufacturer in Shandong / brick machine supplier ( Hongfa )
| Technical parameters : | ||||||||
|
Exciting force(KN) |
Vibration frequency(HZ) |
Molding method |
control mode |
Molding cycle(s) |
Dimension (mm) |
Netweight of host machine |
Pallet |
Total power(kw) |
| 80 | 0-60 |
automatic charging, vibrating and pressing |
Full automatic PLC control |
15-20 | 7500*2100*3020 | 9T | 1020*900*20 | 41 |
| Productivity : | ||||||||
| Item | block size(mm) | Qty per mold |
Molding cycle |
Qty per hour | ||||
| Hollow block | 4000*200*200 | 8pcs | 15-20s | 1440-1920pcs | ||||
| Porous block | 240*115*90 | 18pcs | 15-20s | 3240-4320pcs | ||||
| Solid brick | 240*115*53 | 45pcs | 15-17s | 8100-10800pcs | ||||
QT8-15D Sand cement brick machine manufacturer in Shandong / brick machine supplier ( Hongfa )
Brick samples :
QT8-15D Sand cement brick machine manufacturer in Shandong / brick machine supplier ( Hongfa )
Raw material :
Raw material is widely, like :Crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, and other industrial wastes.
Production line design :
QT8-15D major block machine is an automatic type , the production line can be designed by your ideas and local situation .
The support equipments can be chosen in each section to make production line according to your exact need.
<< material store , batching , mixing section >>
1,cement silo 50T or 100T
2,cement and water scale
3,Screw conveyor
4,batching machine PLD1200
5,conveyor belt 8m
6,JS750mixer
<< Block molding section >>
1,QT8-15D block machine
2,mould
3,Pallets
<<Second materal feeding section for color paver or curbstone>>
1,Second material feeding machine
2,mixer for second material
3,conveyor belt for second material
<< Finished blocks transfering section >>
1,Stacker
2,forklift or fully automatic finger cart
<< Blocks curing section >>
curing in the sun or in the curing room by boiler
Simpel production line:
kind one :
1,Major QT8-15D block machine
2,JS750mixer
3,8m conveyor belt
4,Pallets
Kind two:
1,Batching machine PLD1200
2,JS750mixer
3,8m conveyor belt
4,Major QT8-15D block machine
5,Stacker
6,manual forklift
7,Pallets
If you like to share you opinion , i can help you make a design .
QT8-15D Sand cement brick machine manufacturer in Shandong / brick machine supplier ( Hongfa )
Land and labour need :
Needs 5-6 labour from mixing and transfering finished blocks , the working aera needs 200m2 for simple production line , the raw material store and finised blocks store depends on the local situation .
Service :
We can give one year warranty time for free service , in the period , we can send our engineer to customers place for installaion and training . For any help in the machine whole using life , you can feel free to contact with our after sale deparment for 24 hours.
1.Delivery time:within 30 days after receipt of the deposit
2.payment:30% advance payment by T/T, the balance payment by T/T or L/C.
3.Warranty: 1 year.
4.Spare parts: 1 set of the spare parts and 1set of the tools.
5.We will supply the design layout; we will dispatch the engineer to your side for the installing machine, training your workers. and the buyer only pay for the airtickets, the foods and the hotel for our engineer .
Shipping container need :
Major QT8-15D block machine,JS750mixer,and 8m conveyor belt can be put in one 40HQ container when delivery,if need other support equipments cubic meters,please kindly let me know,i will help you check.
Thanks for your time !
For any help , please feel free to contact me !
Sale manager : Amy Liu MB:0086 13969983506 Skype: donghaowen66
