Ceramic ball mill description
Ceramic ball mill is mainly used for material mixing, grinding, the product fineness uniform, to save power. Can dry grinding can also be wet. The machine according to production needs of different types of liners to meet different needs. Fineness of grinding operations, relying on self-control of grinding time. Electric Pass Auto decompression machine to start, reduce the starting current, its structure is divided into the overall style and stand-alone. The ceramic ball mill with less investment than similar products in energy-saving energy-saving, novel structure, easy operation, use of safe, stable and reliable performance, and other characteristics, suitable for general and special materials, mixing and grinding operations. Users based on the proportion of materials, hardness, and in accordance with production and other factors to consider the appropriate model and linings, media types.
Ceramic Ball Mill Characteristics:
Ceramic ball mill has the features of less investment, saving energy and electricity compared with the similar products,novel
structure, simple operation, useing safely,stable and reliable performance,etc..Ceramic ball mill is applicable to mixing and
grinding operation of the ordinary and special materials. Users can select the appropriate type and liner,media type according
to considering the materials proportion,hardness,production capacity and other factors.
Working Principle:
Our ceramic ball mill is of horizontal, cylindrical and tubular structure. It comes with two cabins and is a grate ball mill. The materials are evenly fed through the charging device to first warehouse where there are step scales boards, corrugated scale boards and different specifications of steel balls. When the cylinder rotates, the centrifugal force produced causes the steel balls to impact and grind the materials in the ball mill. The materials are then lead to the second cabin for further milling until they turn into powders and are discharged from the outlet.
Main Technical Parameters of Ceramic Ball Mill:
Model |
Loading Weight (ton/time) |
Rotate Speed |
Reference Power(KW) |
Liner Material |
600×700 |
0.05 |
50 |
2.2 |
Ceramics, Silica, Rubber, Metal(Equipped power will be a little different according to the liner material and the processed material) |
800×600 |
0.075 |
42 |
3 |
|
900×1200 |
0.2 |
38.5 |
5.5 |
|
1300×1500 |
0.5 |
33 |
7.5 |
|
1500×1800 |
1.2 |
28.5 |
11 |
|
1800×2000 |
1.5 |
24 |
15 |
|
2600×2800 |
5 |
16.5 |
37 |
|
3000×3800 |
10 |
14.5 |
57.2 |
|
3200×4600 |
15 |
13.5 |
75 |
....
