Spiral Pressure Belt

Specifications

Spiral Pressure Belt
Easy installation
Without trace
Strength can reach 100%
long working lifespan

Spiral Pressure Belt





Polyester spiral pressure belts are heat-set at exacting temperature and tension to give maximum operation stability. It is designed for use in solid/liquid separation, as well as sludge dewatering for vacuum and multi-roll belt presses. The unique spiral weave patterns offer rapid drainage and outstanding cake release.



PFM polyester spiral pressure belt offers the following advantages:

• Acidic resistance,
• Alkaline resistance,
• Corrosion resistance
• Temperature resistant
• A long lifespan of using.
• Stronger than common carpet and cavas
• Smooth surface of mesh,
• Strong bursting strength,
• Good permeability,
• Excellent conduct electricity and saving energy.
• Easy installation and without trace,
• Strength can reach 100% compare with general mesh.



Technical Index of polyester spiral pressure belt:



Weaving Type	Model	Thread Diameter (mm)			Air permeability (m³/m²h)
		Warp	Weft	filled with stuff
Large Loop	4070	0.9	1.1	0.9×4	5500±500
				0.9×5	4500±500
Medium Loop	3868	0.7	0.9	0.8×3	4750±500
				0.8×4	4200±500
Small Loop	3252	0.52	0.7	0.68×3	15000±500







Typical Applications of polyester spiral pressure belt are:







A long experience in the field of industrial fabrics and a constant attention to ecology have allowed PFM to develop a wide range of polyester spiral pressure belts for mechanical dewatering of liquid to solid for any kind of material.



- Our product range covers all sludge belt press liquid filtration applications, such as:
- Dewatering of inert sludge from quarries or mines
- Dewatering of biological or chemical sludge from municipality sewage plants
- Pressing of grapes, fruit and others
