Charcoal Briquetting Process Machine

Charcoal Briquetting Process Machine

Charcoal Briquetting Process Machine Introduction:

(1) Charcoal Briquetting Process Machine, mainly used in the production of press sludge, directly into the furnace to smelt and increase the added value.

(2) Any metallurgical industry wastes which all need to be smelted in the furnace,have to be completed by ball press machine, such as furnace dust, mud, oxide iron, steel slag, iron concentrate, aluminum ash, silicon manganese and so on.

(3) Charcoal Briquetting Process Machine is widely used in metallurgy, refractories, power plant, chemical industry, energy, transportation, heating and other industries, has good economic and social benefits.

Charcoal Briquetting Process Machine Customer Cautions:
(1) The particle size of the raw material should be between 0-5mm.
(2) Dry powder Charcoal Briquetting Process Machine can not contain impurities, especially large metal. Such as nails, or iron, rocks, it very likely damage roller and spindle..
(3) The feeding of whole production line should be stable, even, ensure workloads of dry powder briquette machine stable, to get high efficiency of production.

Charcoal Briquetting Process Machine Working Principle:

(1) This series of  Charcoal Briquetting Process Machine will pass the powder on to the two pressure roller through the reducer.

(2)The two sides and roll rotation, in both the rotating roll, natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger.

(3)When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials becomes a finished product from the powder ball.

Charcoal Briquetting Process Machine Technical Parameter:

Model: KF1450-850-350

Reducer: ZS1450

Ratio: 63

Roller Size: 850*350mm

Main Shaft Speed: 7-9r/min

Matched Power: 132kw

Capacity: 15-16t/h

Pressure Type: Constant Pressure/Hydraulic Pressure

Roller Material: 65Mn, 9Cr2Mo, high chrome alloy
