Oil field dirty oil shaftless screwconveyor
Adopt explosio-proof reducer, the pad board is made of mylon and teflon and has good oil-proof ability, not easy to cohere. It is suitable for conveying dirty oil and sludge.
Sewage treatment conveyor
External body is made of stainless steel and gasket is made of engineering plastics. The conveyor is used for conveying garbage and dirt coming from sewage disposal factory.
Summary
Shaftless screw conveyor according to building materials, chemical, environmnental protection,electrec power, medicine, netallurgy, dood industries in the LS spiral, GX model screw conweyor conveying grinding of large, ciscous cut, easy to agglomerate,wrapping easily material form material jams. Hanging bearing damage that spiral machine can not work normally and the actual situation of independent reaearch and development of a new screw conveypr. The procucts are suitable for conceying a continuous uniform loose, sticky, and prone to tangling material, conveying material temperature can be as high as 100 degree, maximum Angle is less than 45 degree.
Shaftless screw conveyor structure
This product mainly by the dvive device, chassis assembly, shaftless helicoid, tub lining board, charging hopper, discharging mouth, machine cover, base etc.
Shaftless screw conveyor characteristic
Without shaft screw conveyor and traditional shaft screw conveyor is compared, due to the center axis is adopted, sling bearing design, use has certain the whole steel spiral push flexible material, thus has the following prominent advantages:
- spiral with super wear resistance and durability and long service life.
- sesistance of winding sex strong: no center axis interference, for conveying belt,and prone to tangling material is special advantages, prevent accidents caused by blocked.
- environmental protection performaces is good: adopt totally closed conveying and cleaning the spiral surface, can ensure environmental health and conveying material from pollution, no leakage.
- torque is big, low energe consumption: because without shaft, material not easily spiral jams, and therefore can be lower running speed, smooth transmission, reduce the energy consumption.
- large transportation amount: throughput is the same diameter has axial xonveyor traditional 1.5 times, the biggest of 40 m3/h, long destance transportation of 25m, and can according to the needs of user, use multilevel tandem installation, long distance transmission materials.
- compact structure, convenient operation, economic durable, maintenance is few, maintenance costs low.
Sewage treatment material conveying quantity:
Type |
Screw width (mm) |
|||||
40 |
60 |
80 |
100 |
120 |
150 |
|
XLS215 |
0.9 |
1.6 |
|
|
|
|
XLS240 |
1.2 |
2.4 |
3.6 |
|
|
|
XLS280 |
1.5 |
3.5 |
4.2 |
|
|
|
XLS320 |
|
4.2 |
5.2 |
7.0 |
|
|
XLS360 |
|
|
6.3 |
8.8 |
|
|
XLS420 |
|
|
8.0 |
11.0 |
14.0 |
|
XLS480 |
|
|
10.0 |
13.5 |
17.5 |
|
XLS540 |
|
|
|
16.0 |
21.0 |
29.0 |
XLS600 |
|
|
|
19.0 |
24.7 |
34.0 |
Remark: the gauge display is the conveying quantity under the rotating speed n=20circles/min screw width
Building, chemical, elcetrical, electricity power, food industries conveying quantity
Screw diameter |
215 |
280 |
360 |
420 |
480 |
600 |
800 |
distance |
190 |
280 |
300 |
320 |
400 |
480 |
500 |
Speed(n/min) |
40 |
40 |
40 |
40 |
40 |
32 |
32 |
Capacity(m3/h) |
9 |
25 |
55 |
80 |
120 |
175 |
300 |
Speed(n/min) |
30 |
30 |
30 |
30 |
30 |
25 |
25 |
Capacity(m3/h) |
7 |
19 |
40 |
60 |
90 |
135 |
230 |
Remark: the speed allowance should be within 10%
Our service
- Operation instruction will be offered by telephone or e-mail if you need.
- Technicians also can be arranged to help set up your project.
- Data sheet will be sent to you if you need.
If you have any question, please tell us, we will do our best to help you!
We are professional manufacturer of various bar screen machine, wastewater treatment equipment, filter press, belt filter press, and vacuum filter, dissolved air floatation etc, and can supply you the most cost-effective products with best price!
Shaftless conveyor with good quality
