Specifications
2014 Hot sale 50/60Hz 1600w hot plastic welding gun or pvc welding gunWelding of HDPE,LDPE,PVC,EVA
Delivery by DHL,UPS,TNT
Hot sale 1600w hot plastic welding gun or pvc welding gun
Please read operating instructions carefully before use and keep it for further reference.
PVC Welding gun parameters>>>
| Product | Welding machine/ hot wedge welder |
| Model | BPM 1600 |
| Description | * Voltage: 230V * Power: 1600W * Frequency: 50/60 Hz * Temperature: 20~700 °C distance adjustable * Air volume : Max 180L/Min * Air pressure: 2600 pa * Noise level : 65 db * Net Weight: 1.05 KGS * Size : 41*15.5*12.5cm |
Hot air tool (PVC welding gun) operation pictures>>>
PVC Welding gun Application>>>
l Welding of thermoplastic materials as well as single-ply flexible plastics and modified bitumen in the
form of boards, tubes, profiles, lining membranes, coated materials, films, foams, tiles and sheets. The
following procedures are possible: overlap welding, welding with rod, with tape, butt welding and melt
welding.
l For foaming, ending and sealing of the thermoplastic semi-finished materials and plastic granules.
l Drying of water-damp surfaces.
l Shrinking of heat-shrink sleeves, films, tapes, solder sleeves, preformed and mould part.
l Soldering of copper pipes, solder joints and metal foils.
l Defrosting of frozen water pipes.
l Activating and dissolving of solvent free adhesive and fusion adhesives
l Igniting of wood shavings, paper, coal or straw in furnaces
Welding gun Changeable nozzles>>>
Do not touch the hot nozzle and make sure to place it on a heat resistant surface because of the fire hazard..
Put the nozzle on the heater tube and secure the nozzle by the screw on the cap.
Use nozzles only.
Maintenance>>>
l Clean polluted air filter with a small brush or replace it
l Clean welding nozzle with a steel brush.
l Check mains cable and plug for electrical and mechanical damage.
Service and repairs>>>
l The motor switches off automatically when the brush reach their minimum length. Have the tool checked by
your service center. The life of the brushes is about 800 hours.
l Repairs should be carried out by authorized service centers only. They guarantee a specialized and reliable
service.
l Sorry for not special notice in advance if there would be changes on parameters.
Shipping of hot air tool(welding gun)>>>
For more quantity and order hdpe geomembrane,it can be shipped into container together.
HDPE Geomembrane
Geotextile PET or PP
Welcome your inquiry and sample order
