Specifications
Full automatic excellent quality vertical packing machine1, New design
2, Fully automatic
3, CE,ISO
Full automatic excellent quality vertical packing machine
vertical packing machine Features It is suitable for non-sticky, bulk or granule medicines, foodstuff and seeds, such as granulated juice sugar, coffee, salt, spice, seasons, melon seeds, rice, oatmeal, loose tea leaf, fragile food, tea,desiccant, washing powder, mono sodium glutamate, popcorn, potato chips, plantain chips, and snacks etc.
The advantadge of vertical packing machine This vertical packing machine can also use the VOLUMETRIC CUP AND MEULTIHEAD ELECTRIC WEIGHER as measuring systerm.
Power of vertical packing machine in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to
customer Local voltage
vertical packing machine Capacity 100-150kg/h(TES 65 Extruder), 250-300kg/h(TES70 Extruder),300-500kg/h(TES 85 Extruder),
Vertical packing machine Technical parameters
| Model | SRK-398 | SRK-520 | SRK-720 |
| width of packing film | Max. 400mm | Max. 520mm | Max. 720mm |
| Thickness of packing film | 0.04-0.08mm | 0.04-0.08mm | 0.04-0.08mm |
| Bag length | 50-300mm | 80-250mm | 100-450mm |
| Bag width | 50-190mm | 100-250mm |
150-350mm |
| Range of measuring | Max.1500mg | Max.2000mg | Max.4000mg |
| Packing speed | 15-90bag/min | 10-70bag/min | 5-40bag/min |
| Voltage | 3.0Kw/220V, 50/60Hz | 3.0Kw/220V, 50/60Hz | 4.0Kw/220V, 50/60Hz |
| Dimension | 1400×970×1700mm | 1430×1200×1700mm | 1780×1350×2000mm |
| Total weight | 400kg | 600kg | 700kg |
What are characteristics of vertical packing machine 1. Siemens PLC computer system and Schneider frequency converter, function is more stable, adjustment any parameters not need stop machine. And English and Chinese screen display,operation is simple.
2. It can stock ten dispose, simple to change variety.
3. Sever motor drawing film, position accurately.
4. Temperature independent control system,precision get to±1°C.
5. Horizontal, vertical temperature control, suitable for various of mix film, PE film packing material.
6. Packing type diversification, pillow sealing, standing type,punching etc.
7. Bag–making, sealing, packing, print date in one operation.
8. Work circumstance quiet, low noise.
Packing Materials and Bag Sample by vertical packing machine Paper/PE, PT/PE, PET/plated AL/PE, PET/PE, BOPP film, and other materials can be heat sealed composited film
vertical packing machine Optional Device
vertical packing machine Packaging Show
1. Testing Machine before package
2. Package : Inside plastic bag, outside wooden case
Every clients will enjoy our services as follow( vertical packing machine ):
Pre-sale service1.Related machines’s technical parameter will be supplied to customer.
2.According to customer’s factory size, factory layout can be provided in advance.
3. According to customer’s material cost, general formulation can be prepared well.
4.Special machine can be supplied as customer’s request.
5.Professional Advice about Market, machines, processing , materials, packing
can be supplied
6. Suggesting professional ship agent or helping book ship as customer request.
After sale service:
1.Allocation chart as the buyer’s request will be supplied.
2.Operation manual will be supplied after shipment.
3.One year warrantee, life time maintenance with cost price.
4.Free easy broken spare parts will be sent with container .
5.First installation can be done by engineer.
6.Training workers in customer’s factory.
Our partner around the world(vertical packing machine )
Certifications Show(vertical packing machine )
Any question about vertical packing machine, pls feel free to contact us
