Specifications
High quality stainless steel automatic bagging machine1.Automatic
2.Flexible design
3.High Precision
4.CE,ISO9001
High quality stainless steel automatic bagging machine
Application
Suitable to package fragile materials demanding high accuracy, such as puffed food, corn flakes, pet food, baby food, crispy rice, jelly, candy, pistachio, apple slices, dumpling, chocolate, small hardware’s, medicine, etc.
It can be three side, four side and back side sealing.
With different size of bags, it is only need to adjsut the former or change the former, and easy to operate!
Feature:
1. All stainless steel cover meets to GMP standard
2.Be suitable for hot filling and assembling attemperator depend on customer's requirement.
3. Automatic adjustment of pouch size and filling range
4. Automatic self-support lubricating system,the machine can work 24 hours
5. The operation facility is controlled by American intel computer,all function is displayed with digital screen
6. Mininum sealing temperature variation employs PID temperature, the tolerance is controlled by 2%
7. Be equipped with a product stirrer and heated jacket for high temperature product packaging.
8. Ink printer and conveyor are as an option
Working Processing :
Bag making → measuring → filling → sealing → cutting → counting → hot pressing codes
Technical Parameter:
| Model | SRK-398 | SRK-520 | SRK-720 |
| width of packing film | Max. 400mm | Max. 520mm | Max. 720mm |
| Thickness of packing film | 0.04-0.08mm | 0.04-0.08mm | 0.04-0.08mm |
| Bag length | 50-300mm | 80-250mm | 100-450mm |
| Bag width | 50-190mm | 100-250mm | 150-350mm |
| Range of measuring | Max.1500mg | Max.2000mg | Max.4000mg |
| Packing speed | 15-90bag/min | 10-70bag/min | 5-40bag/min |
| Voltage | 3.0Kw/220V, 50/60Hz | 3.0Kw/220V, 50/60Hz | 4.0Kw/220V, 50/60Hz |
| Dimension | 1400×970×1700mm | 1430×1200×1700mm | 1780×1350×2000mm |
| Total weight | 400kg | 600kg | 700kg |
Details of automatic bagging machine
Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage
according to different countries.
1.Technical support online service provided
2.Technical file service provided
3.On-site training service provided
4.Engineers available to service machinery overseas
Jinan Sunward Machinery Co., Ltd is an industry and trade integrated enterprise. The company is committed to R & D extrusion machinery and related ancillary equipments. It is covering mainly machinery and equipment for corn meal milling system, corn flakes/breakfast cereal system, baby food system, corn puff snacks system, pellets system, artificial rice system,soy nuggets system; as well as pet food/fish food system.
