Specifications
sprinkler irrigation system1.used for watering large farmland
2.pipe rewind by itself
3.flexible to move
4.with ISO
Agricultural Sprinkler Irrigation System
Description
The irrigation machine mainly adapted to focus on contiguous irrigation of crops such as grains, vegetables, herbs, potatoes and
other crops.It also can spray fruit trees, nursery, and you can spray fertilizers, pesticides and herbicides.
Features
1. Atomization effect
As intense pressure of spray gun, water after spraying is atomization, easy for field absorption, also not hurting flower and fruits.
2. Automatic recovery system
As water turbine driving, pipe will rewind to wheel by itself, save labour.
3. Galvanized steel
Main parts of the whole machine use galvanized steel, which beauty and anticorrosion, keep it a long life.
4. PE pipe
The pipe is Poly Ethylene pipe, with enough wall thickness,durable in use.
Working show
Technical parameters
Model |
PE Diameter |
PE Length |
Maximum Length Of Tube |
Floe (m3/h) |
Sprinkler Diameter (mm) |
The connection Pressure |
JP65-220 |
65 |
220 |
2×260 |
13-32 |
14-22 |
3.5-10.0 |
JP65-250 |
65 |
250 |
2×290 |
13-32 |
14-22 |
3.5-10.0 |
JP65-300 |
65 |
300 |
2×340 |
13-32 |
14-22 |
3.5-10.0 |
JP75-200 |
75 |
200 |
2×250 |
13-50 |
14-26 |
3.5-10.0 |
JP65-340 |
65 |
340 |
2×380 |
13-28 |
14-22 |
3.5-10.0 |
JP75-250 |
75 |
250 |
2×300 |
13-50 |
14-28 |
3.5-10.0 |
JP75-270 |
75 |
270 |
2×315 |
13-45 |
14-28 |
3.5-10.0 |
JP75-300 |
75 |
300 |
2×345 |
13-38 |
14-26 |
3.5-10.0 |
JP75-320 |
75 |
320 |
2×365 |
13-38 |
14-24 |
3.5-10.0 |
JP75-350 |
75 |
350 |
2×390 |
13-38 |
14-22 |
3.5-10.0 |
JP75-400 |
75 |
400 |
2×435 |
13-30 |
14-20 |
3.5-10.0 |
JP90-230 |
90 |
230 |
2×280 |
17-65 |
16-30 |
3.5-10.0 |
JP90-250 |
90 |
250 |
2×300 |
17-65 |
16-30 |
3.5-10.0 |
JP90-280 |
90 |
280 |
2×320 |
17-65 |
16-30 |
3.5-10.0 |
JP90-300 |
90 |
300 |
2×350 |
17-65 |
16-30 |
3.5-10.0 |
