Specifications
hose reel irrigation1.suitable for big farmland
2.pipe rewind by itself,save labor
3.flexible to move
4.with ISO
Hot Sale Hose Reel Irrigation Machine
Description
Irrigation machine is mainly make up of the chassis, reel, PE pipe, water turbine, gearbox, driving the speed compensation device
and water composition. The key components of water turbines, gearboxes, PE pipe and structural piece are in good or bad quality
of the processing technology directly affects the effectiveness and use of the whole operational life.
Application
The machine mainly adapted to focus on contiguous irrigation of crops such as grains, vegetables, herbs, potatoes and other crops.
It also can spray fruit trees, nursery, and you can spray fertilizers, pesticides and herbicides.
Technical parameters
Model |
PE Diameter |
PE Length |
Maximum Length Of Tube |
Floe (m3/h) |
Sprinkler Diameter (mm) |
The connection Pressure |
JP65-220 |
65 |
220 |
2×260 |
13-32 |
14-22 |
3.5-10.0 |
JP65-250 |
65 |
250 |
2×290 |
13-32 |
14-22 |
3.5-10.0 |
JP65-300 |
65 |
300 |
2×340 |
13-32 |
14-22 |
3.5-10.0 |
JP75-200 |
75 |
200 |
2×250 |
13-50 |
14-26 |
3.5-10.0 |
JP65-340 |
65 |
340 |
2×380 |
13-28 |
14-22 |
3.5-10.0 |
JP75-250 |
75 |
250 |
2×300 |
13-50 |
14-28 |
3.5-10.0 |
JP75-270 |
75 |
270 |
2×315 |
13-45 |
14-28 |
3.5-10.0 |
JP75-300 |
75 |
300 |
2×345 |
13-38 |
14-26 |
3.5-10.0 |
JP75-320 |
75 |
320 |
2×365 |
13-38 |
14-24 |
3.5-10.0 |
JP75-350 |
75 |
350 |
2×390 |
13-38 |
14-22 |
3.5-10.0 |
JP75-400 |
75 |
400 |
2×435 |
13-30 |
14-20 |
3.5-10.0 |
JP90-230 |
90 |
230 |
2×280 |
17-65 |
16-30 |
3.5-10.0 |
JP90-250 |
90 |
250 |
2×300 |
17-65 |
16-30 |
3.5-10.0 |
JP90-280 |
90 |
280 |
2×320 |
17-65 |
16-30 |
3.5-10.0 |
JP90-300 |
90 |
300 |
2×350 |
17-65 |
16-30 |
3.5-10.0 |
For further information, pls contact Hellen !
Tel: +0086-15890098440
