Specifications
sprinkler irrigation equipment1.suit for any size field
2.flexible to move and storage
3.turbine recalling
4.save water
Sprinkler Irrigation Equipment for Large Farmland
This equipment is mainly make up of the chassis, reel, PE pipe, water turbine, gearbox, driving the speed compensation device and
water composition.
The key components of water turbines, gearboxes, PE pipe and structural piece are in good or bad quality of the processing technology
directly affects the effectiveness and use of the whole operational life.
Features
1. Atomization effect
As intense pressure of spray gun, water after spraying is atomization, easy for field absorption, also not hurting flower and fruits.
2. Automatic recovery system
As water turbine driving, pipe will rewind to wheel by itself, save labour.
3. Galvanized steel
Main parts of the whole machine use galvanized steel, which beauty and anticorrosion, keep it a long life.
4. PE pipe
The pipe is Poly Ethylene pipe, with enough wall thickness,durable in use.
Technical parameters
Model |
PE Diameter |
PE Length |
Maximum Length Of Tube |
Floe (m3/h) |
Sprinkler Diameter (mm) |
The connection Pressure |
JP65-220 |
65 |
220 |
2×260 |
13-32 |
14-22 |
3.5-10.0 |
JP65-250 |
65 |
250 |
2×290 |
13-32 |
14-22 |
3.5-10.0 |
JP65-300 |
65 |
300 |
2×340 |
13-32 |
14-22 |
3.5-10.0 |
JP75-200 |
75 |
200 |
2×250 |
13-50 |
14-26 |
3.5-10.0 |
JP65-340 |
65 |
340 |
2×380 |
13-28 |
14-22 |
3.5-10.0 |
JP75-250 |
75 |
250 |
2×300 |
13-50 |
14-28 |
3.5-10.0 |
JP75-270 |
75 |
270 |
2×315 |
13-45 |
14-28 |
3.5-10.0 |
JP75-300 |
75 |
300 |
2×345 |
13-38 |
14-26 |
3.5-10.0 |
JP75-320 |
75 |
320 |
2×365 |
13-38 |
14-24 |
3.5-10.0 |
JP75-350 |
75 |
350 |
2×390 |
13-38 |
14-22 |
3.5-10.0 |
JP75-400 |
75 |
400 |
2×435 |
13-30 |
14-20 |
3.5-10.0 |
JP90-230 |
90 |
230 |
2×280 |
17-65 |
16-30 |
3.5-10.0 |
JP90-250 |
90 |
250 |
2×300 |
17-65 |
16-30 |
3.5-10.0 |
JP90-280 |
90 |
280 |
2×320 |
17-65 |
16-30 |
3.5-10.0 |
JP90-300 |
90 |
300 |
2×350 |
17-65 |
16-30 |
3.5-10.0 |
Any question, pls contact hellen !
Tel:+0086-15890098440
