CE approved big biomass sawdust rotary dryer for sale
Rotary Dryer
Introduction:
(1) This rotary drum dryer is widely used to dry powder, pellets, sawdust and other wood materials. Different material will have different capacity, but the capacity can not influence the drying quality;
(2) Simple structure, little malfunction, convenient operation, low maintenance cost;
(3) The machine can be changed according to the nature of the different materials, so that the material inside the dryer drum can form a stable full cut curtain fabric, quality heat exchange is more fully.
Kindly remember: We also have the device to collet smoke and waste gas, which is produced during drying. If you need, please let me know.
Working principle:
Material to be dried enters the dryer, and as the dryer rotates, the material is lifted up by a series of internal fins lining the inner wall of the dryer. When the material gets high enough to roll back off the fins, it falls back down to the bottom of the dryer, passing through the hot gas stream as it falls. Then water will be separated from the materials by hot air-flow and changed into vapor to be discharged into the atmosphere. Then the materials would be dried.
Function of the parts of the dryer:
Hot furnace: provide the hot air for the roller drum, which can dry the material continuously.
Roller drum: the most important of the dryer, the material will be dried inside the roller through the hot air.
Cyclone discharge: it can discharge the finished products to outside, and decrease the pollution.
Drawing of the machine:
Parameter:
Model | Inclination (%) | Capacity (kg/h) | Power(KW) | Rotate speed(r/m) | Inlet air temperature (°C) | Weight(T) |
GT1.0*10 | 3-5 | 900-1100 | 5.5 | 3-8 | ≤220 | 5.6 |
GT1.2*10 | 3-5 | 1300-1500 | 7.5 | 3-8 | ≤220 | 14.5 |
GT1.2*12 | 3-5 | 1500-1700 | 11 | 3-8 | ≤220 | 15 |
GT1.5*12 | 3-5 | 2000-2500 | 15 | 3-8 | ≤220 | 18 |
GT1.8*12 | 3-5 | 3000-3500 | 18 | 2-6 | ≤220 | 25 |
GT2.2*12 | 800 | 4000-4500 | 18.5 | 2-6 | ≤220 | 33 |
GT2.2*18 | 800 | 4500-5500 | 22 | 2-6 | ≤220 | 54 |
GT2.2*20 | 800 | 5500-6500 | 30 | 2-6 | ≤220 | 56 |
More pictures:
Packaging: Wooden Crate or Pallet or bare package in standard containers for export;
Package sample:
Shipping: All machines will be sent by sea, if you need other kind of transportation, please inform us in advance. And all machines would be shipped in 7 days after the receipt of payment. Before and after shipping, we will take photos of machines and send photos to client.


1. Q: Can the logo or company name to be printed on the products or package?
A: Sure. Customer's logo or company name can be printed on products by stamping, printing, embossing, coating or sticker.
2. Q: Can I mix different models in one container?
A: Yes, different models can be mixed in one container, but the quantity of each model should not be less than MOQ.
3. Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.
4. Q: What is your warranty terms?
A: We offer different warranty time for different products. Please contact with us for detailed warranty terms.
5. Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. The core of our company culture is honesty and credit. Also you can check our Alibaba Site, there are several importers' transation History.
6. Q: What's the payment you accept ?
A: As usual our payment is 30%T/T as deposit, and the 70% balance against the copy of B/L. Also we accept the payment such as L/C ,Escrow Or PayPal .
Zhengzhou Megaplant IMP. & EXP. Co., Ltd is located in Zhengzhou city, Henan province in China. The company has been in importing and exporting all kind of machinery and equipments for 8 years and have many customers and friends in over 80 countries and regions.
Our mission is to "Trust and Mutual benefit, Common Development, Keep pace with times and engage in Exploitation and Innovation" spirit of enterprise, and "Honest and Trustworthy, Guarantee the supply, Quick Delivery" business philosophy, establish a stable relationship with domestic and foreign friends.
Anything remaining unclear, please feel free to contact.

Anything remaining unclear, please feel free to contact.
