Industrial 6T/H Sawdust and Coal Rotary Drum Dryer for Sale

Rotary Dryer

Introduction:
(1) This rotary drum dryer is widely used to dry powder, pellets, sawdust and other wood materials. Different material will have different capacity, but the capacity can not influence the drying quality;
(2) Simple structure, little malfunction, convenient operation, low maintenance cost;
(3) The machine can be changed according to the nature of the different materials, so that the material inside the dryer drum can form a stable full cut curtain fabric, quality heat exchange is more fully.

Kindly remember: We also have the device to collet smoke and waste gas, which is produced during drying. If you need, please let me know.

Working principle:
Material to be dried enters the dryer, and as the dryer rotates, the material is lifted up by a series of internal fins lining the inner wall of the dryer. When the material gets high enough to roll back off the fins, it falls back down to the bottom of the dryer, passing through the hot gas stream as it falls. Then water will be separated from the materials by hot air-flow and changed into vapor to be discharged into the atmosphere. Then the materials would be dried.

Function of the parts of the dryer:
Hot furnace: provide the hot air for the roller drum, which can dry the material continuously.
Roller drum: the most important of the dryer, the material will be dried inside the roller through the hot air.
Cyclone discharge: it can discharge the finished products to outside, and decrease the pollution.
Drawing of the machine:

Parameter:

1. Technical data for dryer drum:

2. Technical data for feeding conveyor

Motor power: 2.2kw
Conveyor Length: 6m

Adjustable-speed motor: Yes

3. Technical data for discharge conveyor

Motor power: 2.2kw

Conveyor Length: 5m

More pictures:

Packaging: Wooden Crate or Pallet or bare package in standard containers for export;

Shipping: All machines will be sent by sea, if you need other kind of transportation, please inform us in advance. And all machines would be shipped in 7 days after the receipt of payment. Before and after shipping, we will take photos of machines and send photos to client.

Quality guarantee terms: Quality guarantee is one year. Spare parts we supply at factory cost lifetime.

We will be responsible for any broken which are caused by machine-self and quality problem, other situations which are caused by wrong operation, man-made problems etc will be in buyer’s response, and we will help to solve by video ASAP. If big problem we will send engineer to working site within one week.

Anything remaining unclear, please feel free to contact.
