High Quality Howo 12m3 Concrete Mixer Truck

FOB Price

US$ 60,000 - 105,000 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Henan, China
Brand Name	UNIQUE	Model Number	UT12m ³
Motor Power	276KW	Mixing Power	276kw
Reclaiming capacity	12m³	Speed of Mixing Drum	14-16 r/min
Water Supply Mode	Water pump/Pneumatic Pump	Discharge Way	Counter Revolution of Mixing Drum
Outline Dimension	10730mm2500mm3950mm	After-sales Service Provided	Engineers available to service machinery overseas

howo 12m3 concrete mixer truck
1.With HOWO Chassis
2. Low Leftover Rate (Nearly Zero)
3. Long Service life

howo 12m3 concrete mixer truck

Capacity for your choice: 3 m ³ , 4m ³ ,6 m ³ ,8 m ³ , 9 m ³ 10 m ³ ,12 m ³,14 m ³ ,16 m ³

Overall dimension parameter	Total length(mm)	10730	Engine parameter	Engine model	WD615.96C
	Total width(mm)	2500
	Total height(mm)	3950
	Tank body dimension (Lmm×Φmm)	6724×2450		Rated power(kW/rpm)	276/2200
	Wheel base(mm)	1800+3200+1350		Emission standard	Euro 3
	Min. ground clearance(mm)	260		Fuel type	Diesel
Performance parameter	Chassis manufacturer	Sino truck		Max. speed(km/h)	87
	Chassis type	ZZ1317N3268W		Max.gradability (%)	30
	Kerb mass (kg)	17210		Rated load mass(kg)	13660
Tank body parameter	Mixing volume(m3)	12		Tank lean (°)	9
	Feeding speed(m3/min)	≥3		Top feed hopper dimension(mm)	≥650
	Unloading speed(m3/min)	≥2		Discharge residue rate	≤0.5
Item		Standard Configuration
Chassis parameter	Engine	WD615.96E
	Clutch	B typeφ430 pull style diaphragm clutch
	Transmission	Ten gear transmission
	Steering system	Imported ZF 8098 hydraulic power steering
	Braking system	Dual circuit air-pressure braking system
	Tyre	12.00R20, radial tire
	Air-condition	SINO TRUK special air condition
	Cab type	HW76 flat all metal hydraulic front turning.
Special configuration	Oil pump	ARK PV089
	Hydraulic motor	ARK MF089
	Reducer	TOP P75S
	Water supply system	Water supply by air pressure, 450L water tank
	Accessory	Tool box

Welcome your inquiry!
