Best Supplier of Small Concrete Mixer Truck

FOB Price

US$ 9,999 - 99,999 / Set

1 Set(Min. Order)

Port China Main Port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Henan, China
Brand Name	UNIQUE	Model Number	8m3
Weight	13345/ 11300 KG	Dimension(LWH)	855024963800 mm
Power(W)	213kw	Certification	ISO
Warranty	More than one year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Hot Selling Small Concrete Mixer Truck

Descriptions of Small Concrete Mixer Truck :

7m³, 8m³, 9m³, 10m³ with HOWO Chassis concrete mixer trucks are developed and manufactured on the basis of absorbing the relevant advanced technology home and abroad. The chassis adopted the HOWO brands, which meet the emission stand of European II. Primarily applicable to the concrete transportation and mixing, they can prolong transporting time and guarantee mixing and conveying quality, avoiding layer-by-layer and solidification during transporting in order to guarantee the building progress from German Rexroth and reducer imported from American SAUER Company or German ZF Company. The main components such as the mixing drum and double-screw blades adopt wearing steel-plate 16MnCu materials with the aid of the computer, frame and front-back bed adopt 16Mn steel plate. The upper part of the whole truck adopts roasted progress with abreacting shape, steady and reliable slew, quick discharging, low residue rate, convenient operation, long life , etc . It is ideal essential advanced equipment for concrete plant or mixing station without pollution to the road.

Products Certificate: TUVRheinland CE, ISO9001:2000

Mixing Drum	Mixing Capacity	8 m³	9 m³	10 m³	12 m³	14 m³
	Tank Volume	13.8 m³	14.3 m³	15.96 m³	17.93 m³	24.2 m³
	Angle	15°	12°	12°	12°	11°
	Charging Speed	≥ 3 m³ /min	≥ 3 m³ /min	≥ 3 m³ /min	≥ 3 m³ /min	≥ 3 m³ /min
	Discharging Speed	≥ 2 m³ /min	≥ 2 m³ /min	≥ 2 m³ /min	≥ 2 m³ /min	≥ 2 m³ /min
	Rolling Speed	0~14r/min	0~14r/min	0~14r/min	0~14r/min	0~14r/min
	Residual Ratio of Discharging	Less 0.5%	Less 0.5%	Less 0.5%	Less 0.5%	Less 0.5%
Hydraulic System	Pump	USA Eton or Italy ARK	USA Eton or Italy ARK	USA Eton or Italy ARK	USA Eton or Italy ARK	USA Eton or Italy ARK
	Motor	USA Eton or Italy ARK	USA Eton or Italy ARK	USA Eton or Italy ARK	USA Eton or Italy ARK	USA Eton or Italy ARK
	Reducer	USA Eton or Italy ARK	USA Eton or Italy ARK	USA Eton or Italy ARK	USA Eton or Italy ARK	USA Eton or Italy ARK
Water System	Supply	Air pressure pneumatic	Air pressure pneumatic	Air pressure pneumatic	Air pressure pneumatic	Air pressure pneumatic
Water System	Water Tank	450L ( 400 L )	450L	450L	450L	450L
Truck Chassis	Motor Power	213 KW	247 KW	247 KW	247 KW	273 KW
	Driving	6x4	6x4	6x4	6x4	8x4
	Weight/Rated Load	13345/ 11300 KG	13570/ 11420 KG	13670/ 11520 KG	14530/ 10340 KG	17210/ 13660 KG
	Wheel Base	3600+ 1350 mm	3625+ 1350 mm	3825+ 1350 mm	4025+ 1350 mm	1800+3200+ 1350 mm
	Dimension (L x W x H)	8550x2496x 3800 mm	8900x2496x 3950 mm	9230x2496x 3950 mm	9550x2496x 3950 mm	10550x2496x 3950 mm
