Metal Peforated Corrugated Packing(304.316)

Metal Peforated Corrugated Packing(304.316) thumbnail-1
Metal Peforated Corrugated Packing(304.316) photo-1
US$ 999.9 - 1,599.9 MOQ: 2 Cubic Meters
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
ZHONGYING
Model Number:
125,250Y.500.700
Contact Supplier Request Quote Chat Now
Pingxiang Zhongying Packing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Shanghai and any port in China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangxi, China
Brand Name ZHONGYING
Model Number 125,250Y.500.700

Specifications

1.304.316 stainless steel material, acid-alkali function
2.Long service life, 2 years warranty
3.uniform liquid distribution







 Metal Peforated Corrugated Packing

The packing is made of perforated plate with channel corrugation on surface, and remains structure feature of metal wire gauze packing. It strengthens uniform liquid distribution and surface wetting ability, which increases mass transfer efficiency.



 Metal Peforated Corrugated Packing Technical data

Model

Specific surface
(m2/m3)

Bulk density
(kg/m3)

Void ratio
(%)

Obl.
angle

Δ P
(Pa/plate)

Theo. plate
(piece/m)

125Y

125

100

98

450

200

1~1.2

250Y

250

200

97

450

300

2~2.5

350Y

350

280

94

450

350

3.5~4

500Y

500

360

92

450

400

4~4.5

125X

125

100

98

300

140

0.8~0.9

250X

250

200

97

300

180

1.6~2

350X

350

280

94

300

230

2.3~2.8

500X

500

360

92

300

280

2.8~3.2

 Metal Corrugated Packing Material:, 304, 316, 316L,  Carbonsteels. Aluminium, copper bronze etc. Further materials available on request.

ZhongyingMetal Peforated Corrugated PackingApplication
 Perforated plate corrugated packing with the wide range of applications.
 Diameter: 0.1-12m; Pressure: Vacuum to high pressure;
 Liquid load: 0.2 to more than 300 m3 / m2.h;
 System: Ethyl benzene/ styrene, Fatty acid, cyclohex anone/ cyclohexanol, caprolaction, etc, Absorption desorption.
