Specifications
1)20 years professional manufacture2)Acid resistant ceramic
3)Ontime delivery
4)One-stop service
5)ISO9001:2000
Ceramic structured packing is a kind of column shape and single layer corrugated packing, consisting of many pieces with the same geometric shape and parallel to each other. According to the different obliquity of corrugated sheet, this product is divided into X-style and Y-style, and X and Y correspond to the 30°and 45°respectively.
Applications:
1) Rectifying organic halide.
2) Rectifying and absorbing some corrosive mixtures, which are definitely regulated in pressure drop and theoretic plate number.
3) Applied in some towers that contain a large quantity of natural media used to absorb nitric acid and concentrated sulfuric acid, as well as for purifying the air in chemical plants.
4) Operating in vacuum conditions at a bottom absolute pressure of 100pa.
5) Used in heat exchanger and demisting, or as a catalyst carrier.
Advantages:
Compared with the random packing,It's advantages list below:
(1)larger Void space,can narrowed its diameter when be used to the new tower design,Can enlarge its diameter when be used to the odl old tower to increased the process capacity.
(2)lower pressure drop.
(3)higer separation rate.
Technical date:
|
Type |
Surface area (m²/m³) |
Tilt angle (°) |
Void space |
Number per m³ |
Crushing strength (Pa) |
Hydraulic diameter (mm) |
spray liquid density (M3m2·h) |
Max F-factor M/s·(kg/m3)0.5 |
P Pa/m |
Nt M-1 |
470X |
470 |
30 |
75 |
500-540 |
>2M |
7 |
0.2-100 |
1.8 |
5 |
5 |
|
450X |
450 |
30 |
72 |
480-500 |
>2M |
7 |
0.2-100 |
2.0 |
4.5 |
3-4 |
|
450Y |
450 |
45 |
72 |
500-520 |
>2M |
7 |
0.2-100 |
1.8 |
4 |
4 |
|
400X |
400 |
30 |
75 |
460-480 |
>2M |
8 |
0.2-100 |
2.2 |
4 |
2.8 |
|
400Y |
400 |
45 |
75 |
460-500 |
>2M |
8 |
0.2-100 |
2.0 |
3 |
3 |
|
350X |
350 |
30 |
78 |
400-440 |
>2M |
10 |
0.2-100 |
2.6 |
3 |
2.5 |
|
350Y |
350 |
45 |
78 |
400-440 |
>2M |
10 |
0.2-100 |
2.5 |
2.5 |
2.8 |
|
|
250X |
250 |
30 |
80 |
390-420 |
>2M |
12 |
0.2-100 |
2.8 |
2.5 |
2.3 |
250Y |
250 |
45 |
80 |
390-420 |
>2M |
12 |
0.2-100 |
2.6 |
2 |
2.5 |
|
150X |
150 |
30 |
85 |
220-380 |
>2M |
15 |
0.2-100 |
3.0 |
2 |
1.8 |
|
150Y |
150 |
45 |
85 |
220-380 |
>2M |
15 |
0.2-100 |
2.8 |
1.8 |
2 |
|
125X |
125 |
30 |
90 |
200-230 |
>2M |
28 |
0.2-100 |
3.2 |
1.8 |
1.5 |
|
125Y |
125 |
45 |
90 |
200-230 |
>2M |
28 |
0.2-100 |
3.0 |
1.5 |
1.8 |
|
100X |
100 |
30 |
92 |
190-200 |
>2M |
30 |
0.2-100 |
3.5 |
1.5 |
1 |
Acid resistant ceramic,Ceramic structured packing,ceramic corrugated stuctrued packing,tower internals
Welcome to inquiry!
