Specifications
1)20 years professional manufacture2)High quality and reasonable price
3)Ontime delivery
4)One-stop service
5)ISO9001:2000
Ceramic structured packing is a kind of column shape and single layer corrugated packing, consisting of many pieces with the same geometric shape and parallel to each other. According to the different obliquity of corrugated sheet, this product is divided into X-style and Y-style, and X and Y correspond to the 30°and 45°respectively.
Advantages
1) High capacity. New tower design may reduce diameter, while renovate old towers may increase capacity significantly.
2) High separation efficiency. Since it has much larger specific surface area compared to random packing.
3) Low pressure drop, which leads to reduce energy consumption largely.
Technical data
|
Type |
Surface area (m²/m³) |
Tilt angle (°) |
Void space |
Number per m³ |
Crushing strength (Pa) |
Hydraulic diameter (mm) |
spray liquid density (M3m2·h) |
Max F-factor M/s·(kg/m3)0.5 |
P Pa/m |
Nt M-1 |
470X |
470 |
30 |
75 |
500-540 |
>2M |
7 |
0.2-100 |
1.8 |
5 |
5 |
|
450X |
450 |
30 |
72 |
480-500 |
>2M |
7 |
0.2-100 |
2.0 |
4.5 |
3-4 |
|
450Y |
450 |
45 |
72 |
500-520 |
>2M |
7 |
0.2-100 |
1.8 |
4 |
4 |
|
400X |
400 |
30 |
75 |
460-480 |
>2M |
8 |
0.2-100 |
2.2 |
4 |
2.8 |
|
400Y |
400 |
45 |
75 |
460-500 |
>2M |
8 |
0.2-100 |
2.0 |
3 |
3 |
|
350X |
350 |
30 |
78 |
400-440 |
>2M |
10 |
0.2-100 |
2.6 |
3 |
2.5 |
|
350Y |
350 |
45 |
78 |
400-440 |
>2M |
10 |
0.2-100 |
2.5 |
2.5 |
2.8 |
|
|
250X |
250 |
30 |
80 |
390-420 |
>2M |
12 |
0.2-100 |
2.8 |
2.5 |
2.3 |
250Y |
250 |
45 |
80 |
390-420 |
>2M |
12 |
0.2-100 |
2.6 |
2 |
2.5 |
|
150X |
150 |
30 |
85 |
220-380 |
>2M |
15 |
0.2-100 |
3.0 |
2 |
1.8 |
|
150Y |
150 |
45 |
85 |
220-380 |
>2M |
15 |
0.2-100 |
2.8 |
1.8 |
2 |
|
125X |
125 |
30 |
90 |
200-230 |
>2M |
28 |
0.2-100 |
3.2 |
1.8 |
1.5 |
|
125Y |
125 |
45 |
90 |
200-230 |
>2M |
28 |
0.2-100 |
3.0 |
1.5 |
1.8 |
|
100X |
100 |
30 |
92 |
190-200 |
>2M |
30 |
0.2-100 |
3.5 |
1.5 |
1 |
