4-stroke outboard motor / boat engine

 Marine Outboard Motors

1. Long-Term Reliability
2.Convenient, Economical, Safe
3.Enhanced Corrosion Resistance

1.About the products

A. the description of product

Our Outboard Motor is made by China, an European Power– over 50 years of successful Typical and historical Italian outboards maker , The production cycle of marine engine components is really complete, from the die casting to final packing. More than 20 years the ONLY European company has a complete range of outboard motors: 15 base models & 44 different versions from 2hp to 60hp.

Certificate: CE, ISO9001, SGS

Product Line:

2-Stroke: 2.5hp, 3.5hp, 4hp, 5hp, 6hp, 8hp, 9.8hp, 9.9hp, 15hp, 25hp, 30hp, 40hp, 60hp

4-Stroke: 2.5hp, 4hp, 5hp, 8hp, 9.9hp, 15hp, 20hp, 25hp

B. Drawing,Picture&Dimension of products

2. Features and applications

MODEL#: T25BM (back control, manual start)

H.P.: 25hp

SHAFT LENGTH (Short shaft): 400/15.7 (mm/in)

SHAFT LENGTH (Long shaft): 520/22 (mm/in)

ENGINE TYPE: 2 cylinders, 2 stroke

DISPLACEMENT: 489(cm3)

BORE x STROKE: 72×60(mm)

MAX. OUTPUT: 25/18.4(hp/kw)

MAX. R.P.M. RANGE: 4500~5500(rpm)

Compression Ratio: 6.5

Scavenging Method: Loop

IGNITION SYSTEM: CDI

TRANSMISSION RATIO: 13/27

STEERING: Tiller Handle

Lubrication: PREMIX

STARTING SYSTEM: MANUAL

TRIM METHOD: MANUAL

WEIGHT (Short shaft): 52

WEIGHT (Long shaft): 54

Packed case size (mm): 1380*435*766

Container loading: 20 ft=63 sets, 40 ft=129 sets

*S=Short shaft, L=Long shaft.

A. Excellent service before purchasing

B.M know what the best cost-effective products are. According to clients’ circumstances, we will offer most suitable products for them.

B. Guaranteed quality

Most products which B.M offered are with high quality and also provide warranty to security benefits.

C. Rich experience and Customized Products

B.M has enormous resources of various marine equipment. All of our products are customized. We can offer products according to your detail equipment and drawings.

In all, Biman industrial manufactures and supplies wide range of marine rubber fenders, which have been exported to dozens of countries, such as USA, Australia, Greece, Germany, Singapore, the Philippines, Indonesia, Iraq, Saudi Arabia, Russia, Denmark, Peru, Malaysia, Nigeria, Israel, Turkey, Hong Kong etc. Hope your joining will build our long term cooperation relationship and give mutual benefits to each other.

Your enquiries are always welcome and we will provide professional service to you, no matter for the products or others.

packaging and foctory.

4.Certification To Guarantee We are Good In Quality

6.Contact.
