Help CenterBiogas Generator 120KW/ Biomass Generator/Waste Power Plant 60Hz
Related Products
-
Biogas Generator 100KW/biomass Generator/waste to Energy 60HzUS$ 10,000 - 30,000MOQ: 1 Set -
Biogas Generator80KW/biomass Generatorpower Generation 60HzUS$ 10,000 - 30,000MOQ: 1 Set
-
Biogas Generator 50KW/ Natural Gas Generator50KW/ Biomass Power Plant 60HzUS$ 10,000 - 30,000MOQ: 1 Set
-
Small Biogas Generator 30KW for Sale/ Waste to Energy Power PlantUS$ 10,000 - 30,000MOQ: 1 Set
-
Biogas Generator 24KW for Sale/ Biogas Genset 30KVA/biomass Generator 60HzUS$ 9,000 - 20,000MOQ: 1 Set
Biogas generator set/Biogas genset/biogas engine/Biogas power plant/CHP gas generator/Natural gas generator/Waste to energy euipment with ISO&CE certificates
Genset Specification:
Gas genset data | ||
Genset model |
KDGH120-G |
|
Prime power(kW/KVA) |
120/150 |
|
Continuous power (kW/KVA) |
100/125 |
|
Output Voltage (V) |
220V/127V, 3 Phases 4 Lines |
|
Power factor cosfi |
0.8 lagging |
|
Frequency (Hz) |
60 |
|
Rated speed (RPM) |
1800 |
|
Open type Overall Dimension (mm) |
3000x1100x1800 |
|
Sound proof type Dimension (mm) |
4600x1600x2200 |
|
Net weight without canopy(kg) |
2500 |
|
Gas Engine Data | ||
Model |
HGN14 |
|
Brand |
CAMDA |
|
Type |
4 stroke, water-cooling, wet cylinder liner, electronic-control ignition system, pre-mixed perfect mixed burning |
|
Cylinders& Arrangement |
6L |
|
Bore X Stroke(mm) |
140X152 |
|
Displacement(L) |
14 |
|
Compression ratio |
11:1 |
|
Aspiration |
Natural |
|
Cooling Method |
Radiator |
|
Governor type(speed regulating type) |
Electronic governing |
|
Starting method |
Electric, 24 V motor |
|
The lowest gas consumption(m3/kw.h) |
0.6 |
|
Idling speed(r/min) |
700 |
|
Oil recommended |
SAE 15W-40 CF4 or above |
|
Oil consumption |
≤1.0g/kW.h |
|
Features of Camda H series gas genset:
1. Specially-designed air valves, crankshaft, camshaft, pistons, ignition system and combustion chamber according to gas combustion characteristics.
2. Long life span. Camda gas engine is designed and developed through the cooperation between joint venture and CAMDA. The gas engine life span reaches 30 years.
3. Long designed overhaul term: 25,000 ~ 30,000 hours.
4. Total cogeneration efficiency is around 83%, higher than other China brands by 5%.
5. Four air valves designing for each cylinder. Sufficient air intaking and exhausting to realize maximum power output.
6. Easy access to spare parts. it's very convenient to find any parts at anytime and anywhere.
7. Electronic Air/Gas mixer. The mixer guarantees optimum air-fuel ratio, improves thermal efficiency, reduces NOx emission. Unique air-fuel ratio adjusting system suits 30% ~ 90% methane density.
8. Ignition system. Altronic ignition system imported from USA ensures high-precision ignition, which enhances genset life span and stability.
9. Equipped with world-famous Leroy Somer alternator, providing stable and durable output.
10. Full automatic and intelligent control system IG-NT from Czekh enables easy operation and automatical inspection for genset running status.
11. Production Complying to CE standards, ISO9001:2008 Quality Management System, ISO14001:2004 AND ohsas18001:2007.
12. Free of charge training for operation and maintenance. (at Camda headquarter)
